Gedore DMSE 150 2641453 Torque wrench 9 x 12 mm socket square 30 - 150 Nm
EAN:
Part number:
Item no:
Number
Total (€ 197.47 / piece)
€ 197.47
plus VAT.
14 days return policy included
Technical specifications
- DMSE 150 - GEDORE - torque wrench DREMASTER SE 9x12, 30-150 Nm
- controlled screw suit in the most common range of 30-150 N
- m / 22-110 lbf
- ft (guide value screws M7-10.9 to M20-6.9)
- Adjustable, triggering and robust pipe torque wrench with square-wave holder for industry and trade
- classified according to DIN EN ISO 6789:2003 Type II Class A, With a traceable factory certificate. Calibrated for a permissible deviation of +/- 3 % and better. The specification of the standard (+/- 4%) is exceeded for your safety.
- For the controlled right and left suit robust, semi-gloss chrome-plated steel tube construction, with chrome-plated square holder (9x12 mm) and high-quality plastic parts
- ergonomically shaped, 2-component plastic handle with calibration aid
- Switching between main scale N
- m and secondary scale lbf
- ft, for avoiding reading errors when setting the desired torque.
- With micrometer scale for N
- m main scale for setting scale-wiping values
- of the embrittlement system generates a sensitive and audible trigger signal
- ergonomic system for torque adjustment with indicator symbol
- Possibility of quick adjustment by angle screwdriver,
- not included in the delivery secured adjustment system
- Factory calibration jig measure: 17.5 mm (9x12)
- actuation only with push-in tools with a uniform pitch - otherwise, value shifts may occur
- depending on the tool insert, both forwards (e.g. Open-end wrenches) or to the side (e.g. Reversible ratchet and socket wrench insert).
- Patent pending
- Product type
Torque wrench
- Downforce
9 x 12 mm socket square
- Torque (min.)
30 Nm
- Torque (max.)
150 Nm
- Graduation
10 Nm
- Length
489.5 mm
- Weight
1.306 kg
- Width
27.5 mm
- Height
60 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1908340 Gedore DMSE 150 2641453 Torque wrench 9 x 12 mm socket square 30 - 150 Nm
Information
Information 1908340 Gedore DMSE 150 2641453 Torque wrench 9 x 12 mm socket square 30 - 150 Nm
Description
Features
- Use:
- Controlled screw tightening in the most common range of 20 - 400 N
- m / 15 - 300 lbf
- ft (guide for screws M7-10.9 to M20-6.9)
- Adjustable, releasing and sturdy tubular torque wrench with rectangular cavity for industry and the trades Features:
- Classified to DIN EN ISO 6789:2017 Type II Class A, with a factory certificate allowing for operations to be traced back. Calibrated to a permitted +/- 3 % deviation and better. The specifications of the standard (+/- 4 %) are exceeded.
- For controlled bi-directional tightening
- Sturdy, varnished tubular steel construction, with zinc-plated rectangular cavity (9x12 mm or 14x18mm) and high-grade plastic parts
- Ergonomically shaped plastic grip with calibration aid
- Change-over between N
- m main scale and lbf
- ft ancillary scale to avoid reading errors when setting the torque wanted.
- With micrometre scale for main N
- m scale for setting interim values
- Release system triggers a tactile and audible signal
- Ergonomic system for torque adjustment with reference symbol
- Provision for rapid setting with hexagon allen key, not included
- Secured adjusting/setting system
- Factory depth gauge: 17.5 mm (9x12 mm) or 25 mm (14x18 mm)
- Operation only with end fittings with standardised depth gauges, otherwise inaccuracies can arise
- Depending on the application, access is possible from the front (e.g. open-end fitting) or side (e.g. reversible ratchet and socket)
