Name: HELU 19003 Data transfer cable LiYY 3 x 2 x 0.14 mm² Grey 100 m
Brand: HELU
SKU: 1931458
Availability: InStock

Multi-core cable with visible coloured wires on the left and the inscription 'HELUKABEL PAAR-TRONIC 3x2x0.20 QMM' on the grey outer sheathing on the right.

Image similar

Product type

Data transfer cable

No. of leads

6 x

Cross section (each core)

0.14 mm²

Cable features

PVC coating

Flexible

incl. graduation (metres)

Flame-retardant

largely oil-resistant

Cable type

LiYY

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

2 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Set(s)

Total (1 m = € 0.96)

€ 95.99

incl. VAT

Only 2 Set(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: Data transfer cable

Cable type: LiYY

No. of leads: 6 x

Cross section (each core): 0.14 mm²

Twisted pair cabling (part 1): Yes (1)

Cross section: 3 x 2 x 0.14 mm²

Twisted pair cabling (yes/no): Yes (1)

Cable features: PVC coating
Flexible
incl. graduation (metres)
Flame-retardant
largely oil-resistant

Outside Ø: 5.10 mm

Factory colour: Grey

Content: 100 m

Test voltage: 1200

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Packaged: Yes

Sold per metre: No

Halogen-free: No

Shielded: No

Manufacturer part #: 19003

Insulation material: PVC

Wire ID code: DIN 47100

Core layout: Plain Cu

Min. temperature range (flexible installation): -5 °C

Max. temperature range (flexible installation): +80 °C

Min. temperature range (fixed installation): -30 °C

Max. temperature range (fixed installation): +80 °C

Certification marks: In accordance with DIN VDE 0812 and 0814;EAC

Peak operating voltage: 350 V

Type: PAAR-TRONIC
