Kübler Group Codix 532 Digital Thermometer Display -19999 -99999 ºC °C
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 194.99 / piece)
€ 194.99
incl. VAT
14-day return policy included
Highlights & Details
Temperature display Codix 532
- Assembly dimensions 45 x 22 mm
Technical specifications
- Product type
Meter
- Type
Codix 532
- Dim
(W x H x D) 48 x 24 x 69 mm
- Width
48 mm
- Height
24 mm
- Digit height
8 mm
- Depth
69 mm
- Digits
5
- Assembly dimensions
45 x 22 mm
- Accuracy
Depending on sensor
- Total dimensions
48 x 24 mm
- Temperature
-19999 -99999 ºC °C
- Sample rate
0.2 s
- Temperature resolution
0,1 oder 1 °C/ °F
- Operating voltage
10 - 30 V DC
Documents & Downloads
Datasheet
Datasheet 120997 Kübler Group Codix 532 Digital Thermometer Display -19999 -99999 ºC °C
User & Safety Instructions
User & Safety Instructions 120997 Kübler Group Codix 532 Digital Thermometer Display -19999 -99999 ºC °C
Description
Temperature display in º C or º F × Min.-/Max.Value capture and data storage at power off · Galvanically separated reverse polarity protection · Screw terminal connection 5 mm grid · Easy to programme and operate · Uniform Codix design · 5 measurements per second · Latch input for display storage.
Features
- Input ranges Codix 532: thermo couples, J, K, N with external or internal reference point compensation.
