Buy LAPP ÖLFLEX® HEAT 180 C MS High-temperature cable 5 G 1 mm² Black 46711/1000 1000 m | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

Close-up of a cable with the inscription: "CAP RAGEX S/UVOR 0.6/1kV HEAT 90 C 25 IR AWM STYLE 4495 CSA AWM I/II A/B 600V 150C FT1 CE".

Close-up of a cable with the inscription: "CAP RAGEX S/UVOR 0.6/1kV HEAT 90 C 25 IR AWM STYLE 4495 CSA AWM I/II A/B 600V 150C FT1 CE".

Image similar

LAPP

Product type

High-temperature cable

No. of leads

5 G

Cross section (each core)

1 mm²

Cable type

ÖLFLEX® HEAT 180 C MS

Outside Ø

11 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (1 m = € 11.52)

€ 11,515.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Oilflex ® HEAT 180 C MS

Technical specifications

Product type: High-temperature cable

No. of leads: 5 G

Content: 1000 m

Cross section (each core): 1 mm²

Cable features: Halogen-free
Shielded
Flame-retardant
Oil-resistant
Heat-resistant

Cable type: ÖLFLEX® HEAT 180 C MS

Outside Ø: 11 mm

Packaged: Yes

Wire ID code: Colored according to VDE 0293-308, see Annex T9
From 6 wires black with white numbers

Bend radius (no. of ODs for fixed installation): 6

Bend radius (no. of ODs for flexible installation): 20

Halogen-free: Yes

Manufacturer part #: 46711/1000

Factory colour: Black

Insulation material: Silicone

Core layout: Finely stranded according to VDE 0295, Class 5/IEC 60228 Cl.5

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Test voltage: 2000 V

Cross section: 5 G 1 mm²

Max. temperature range (flexible installation): +180 °C

Min. temperature range (flexible installation): -50 °C

Max. temperature range (fixed installation): +180 °C

Min. temperature range (fixed installation): -50 °C

Type: ÖLFLEX HEAT 180 C MS 5G1,0

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 1335219 LAPP ÖLFLEX® HEAT 180 C MS High-temperature cable 5 G 1 mm² Black 46711/1000 1000 m

User & Safety Instructions

User & Safety Instructions 1335219 LAPP ÖLFLEX® HEAT 180 C MS High-temperature cable 5 G 1 mm² Black 46711/1000 1000 m

Description

Oilflex ® HEAT 180 C MS-silicone connection and control line shielded, UL/CSA AWM approved for use in North America in the machines and equipment to +180 °C. Areas with high environment temperatures where insulation and sheathing materials of conventional cables and leads to become brittle and becoming brittle. Typical applications: steel, ceramic and steelworks, bakery machines and industrial furnaces, electric motor industry, Sauna and Solaria construction, thermal- and heating elements, lighting, fan construction, air conditioning, galvanising, plastic processing, Generators -and Transformators construction, wind power plant construction.

This text is machine translated.

Description

Oilflex ® HEAT 180 C MS-silicone connection and control line shielded, UL/CSA AWM approved for use in North America in the machines and equipment to +180 °C. Areas with high environment temperatures where insulation and sheathing materials of conventional cables and leads to become brittle and becoming brittle. Typical applications: steel, ceramic and steelworks, bakery machines and industrial furnaces, electric motor industry, Sauna and Solaria construction, thermal- and heating elements, lighting, fan construction, air conditioning, galvanising, plastic processing, Generators -and Transformators construction, wind power plant construction.

This text is machine translated.
