Marquardt 1006.1201 Microswitch 1006.1201 250 V AC 10 A 1 x On/(On) momentary 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 6.34
5
6% = € 0.38
€ 5.96
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 6.34 / piece)
€ 6.34
plus VAT.
Highlights & Details
Snap switch series 1005
Technical specifications
- Approvals ENEC, UL, CSA
- Functions
momentary
- Connection
Type C CEE 7/16 plug 6.3 mm
- Contact material
Ag (Silver)
- Operation type
Lever
- Contact type
1 change-over
- Switch position
1 x On/(On)
- Switching voltage
250 V AC
- Switching current (max.)
10 A
- Length
10.3 mm
- Width
28 mm
- Height
16 mm
- Actuating force
2.5 N
- Content
1 pc(s)
- Dim
(L x W x H) 10.3 x 28 x 16 mm
- Type
1006.1201
- Type
1 x on/(on)
- Switching current
10 (4) A
- Type
1006.1201
- Actuating force
1.5 - 2.5 N
- Connection
Spade plug 6.3 mm
- Product type
Microswitch
Documents & Downloads
Datasheet
Datasheet 703145 Marquardt 1006.1201 Microswitch 1006.1201 250 V AC 10 A 1 x On/(On) momentary 1 pc(s)
Description
Micro switch with rubbing contact system whose shearing movement can release welding.
