Name: MEAN WELL DDR-240D-48 Rail mounted DC/DC converter (DIN) 48 V DC 5 A 240 W No. of outputs:1 x Content 1 pc(s)
Brand: MEAN WELL
SKU: 2113589
Availability: InStock

Industrial DIN rail power supply, Model DDR-240D-24, 24V, 10A, by Mean Well, suitable for installation in control cabinets.

Datasheet (PDF)

Fast track dispatch on Thu 15 Oct

5 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 109.99 / piece)

€ 109.99

incl. VAT

Only 5 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

MEANWELL DC/DC converter series DDR-240 for DIN rail Single Output Input voltage ratio: 2:1 Power: 240 W

For DIN rail mounting.
Can be used on DIN-rail TS-35/7.5 or 15 can be installed
Width of only 40 mm
2:1 input voltage range
150% peak load capacity
Regulated output voltage
Cooling by free air convection
Input/output insulation 4000 V
Protection: short circuit, overload, overvoltage, overheating, input polarity, input under voltage protection
This text is machine translated.

Technical specifications

Product type: Rail mounted DC/DC converter (DIN)

Min. input voltage: 67.2 V DC

Output voltage: 48 V DC

Input voltage: 67.2-154 V DC

Input voltage (max.): 154 V DC

Max. output current: 5 A

Output current (max.) - rounded: 5 A

: 240 W

Output type (power supply units): Adjustable

Output voltage (nominal): 48 V DC

No. of outputs: 1 x

Connection: Clamp

Dim: (L x W x H) 40 x 113.5 x 125.2 mm

Weight: 760 g

Output voltage (max.): 54 V DC

Output voltage (min.): 48 V DC

Operating temperature (max.): +70 °C

Operating temperature (min.): -40 °C

Manufacturer part #: DDR-240D-48

Content: 1 pc(s)

MTBF: 484900 h

PSU features: DC-to-DC converter
Regulated
Adjustable voltage output

Width: 113.5 mm

Height: 125.2 mm

Length: 40 mm

Type: DDR-240D-48

Efficiency: 92.5 %

UKCA: yes

Compliance & Certifications

Certified by EU Garan

Variants(All information include VAT, plus shipping costs)

Power

Input voltage (max.)

Output voltage (nominal)

Output voltage

Nominal input voltage

Output current (max.) - rounded

Min. input voltage

MEAN WELL DDR-120A-12 Rail mounted DC/DC converter (DIN) 12 V DC 8.3 A 99.6 W No. of outputs:1 x Content 1 pc(s)

Item no:2113637

Fast track dispatch on Thu 15 Oct

70 Piece(s)Conrad Electronic

99.6 W

18 V DC

12 V DC

12 V/DC

8.3 A

9 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120A-24 Rail mounted DC/DC converter (DIN) 24 V DC 4.2 A 100.8 W No. of outputs:1 x Content 1 pc(s)

Item no:2113540

Fast track dispatch on Thu 15 Oct

5 Piece(s)Conrad Electronic

100.8 W

18 V DC

24 V DC

12 V/DC

4.2 A

9 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120A-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.1 A 100.8 W No. of outputs:1 x Content 1 pc(s)

Item no:2113420

Fast track dispatch on Thu 15 Oct

70 Piece(s)Conrad Electronic

100.8 W

18 V DC

48 V DC

12 V/DC

2.1 A

9 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120B-12 Rail mounted DC/DC converter (DIN) 12 V DC 10 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113561

Fast track dispatch on Thu 15 Oct

33 Piece(s)Conrad Electronic

120 W

33.6 V DC

12 V DC

24 V/DC

10 A

16.8 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120B-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113475

Fast track dispatch on Thu 15 Oct

56 Piece(s)Conrad Electronic

120 W

33.6 V DC

24 V DC

24 V/DC

5 A

16.8 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120C-12 Rail mounted DC/DC converter (DIN) 12 V DC 10 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113541

Fast track dispatch on Thu 15 Oct

7 Piece(s)Conrad Electronic

120 W

67.2 V DC

12 V DC

48 V/DC

10 A

33.6 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120C-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113498

Fast track dispatch on Thu 15 Oct

9 Piece(s)Conrad Electronic

120 W

67.2 V DC

24 V DC

48 V/DC

5 A

33.6 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120C-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113421

Fast track dispatch on Thu 15 Oct

25 Piece(s)Conrad Electronic

120 W

67.2 V DC

48 V DC

48 V/DC

2.5 A

33.6 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120D-24 Rail mounted DC/DC converter (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113499

Fast track dispatch on Thu 15 Oct

3 Piece(s)Conrad Electronic

120 W

154 V DC

24 V DC

5 A

67.2 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 75.99^*

MEAN WELL DDR-120D-48 Rail mounted DC/DC converter (DIN) 48 V DC 2.5 A 120 W No. of outputs:1 x Content 1 pc(s)

Item no:2113438

Dispatches on Wed 28 Oct

Conrad Electronic

120 W

154 V DC

48 V DC

2.5 A

67.2 V DC

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 77.99^*

Documents & Downloads

Datasheet

Datasheet 2113589 MEAN WELL DDR-240D-48 Rail mounted DC/DC converter (DIN) 48 V DC 5 A 240 W No. of outputs:1 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2113589 MEAN WELL DDR-240D-48 Rail mounted DC/DC converter (DIN) 48 V DC 5 A 240 W No. of outputs:1 x Content 1 pc(s)

Warranty Terms

Warranty Terms 2113589 MEAN WELL DDR-240D-48 Rail mounted DC/DC converter (DIN) 48 V DC 5 A 240 W No. of outputs:1 x Content 1 pc(s)

Features

Can be used on DIN-rail TS-35/7.5 or 15 can be installed
Width of only 40 mm
2:1 input voltage range
150% peak load capacity
Regulated output voltage
Cooling by free air convection
Input/output insulation 4000 V
Protection: short circuit, overload, overvoltage, overheating, input polarity, input under voltage protection

Description

Features

Can be used on DIN-rail TS-35/7.5 or 15 can be installed
Width of only 40 mm
2:1 input voltage range
150% peak load capacity
Regulated output voltage
Cooling by free air convection
Input/output insulation 4000 V
Protection: short circuit, overload, overvoltage, overheating, input polarity, input under voltage protection
