MEAN WELL MSP-300-12 SMPSU 324 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 139.99 / piece)
€ 139.99
incl. VAT
Only 4 Piece(s) available
Highlights & Details
Switching power supply medical
- Output /
- Power 324 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Min. input voltage
90 V AC
- Dim
(L x W x H) 199.00 x 105.00 x 41.00 mm
- Connection
Screw terminal
324 W
- No. of outputs
1 x
- Output voltage 1
12 V DC
- Output voltage 2
5 V DC
- Type
closed
- Weight
953.33 g
- PSU features
Regulated
- Type
Synchronised
- Width
105.00 mm
- Height
41.00 mm
- Length
199.00 mm
- Type
MSP-300-12
- No. of inputs
1 x
- Output voltage
12 V DC
- Output current (details)
27 A
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1293791 MEAN WELL MSP-300-12 SMPSU 324 W
User & Safety Instructions
User & Safety Instructions 1293791 MEAN WELL MSP-300-12 SMPSU 324 W
Information
Information 1293791 MEAN WELL MSP-300-12 SMPSU 324 W
Warranty Terms
Warranty Terms 1293791 MEAN WELL MSP-300-12 SMPSU 324 W
Description
Enclosed case, built-in fan, screw terminals · Universal input · Overload protection, current limiting, auto recovery · Protections: short circuit/over load/over voltage · Built-in active PFC function · Low no load power consumption when using remote control · Built-in remote On/Off control · Built-in remote sense function · DC OK signal · Built-in auxiliary power, Stand-by 5V/0,3A · EN60601-1 compliant (MOOP level)
Features
- Closed design (case) with fan, screw terminals
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- Low idle power
- Switching on and off of the output voltage via remote signal
- Sensor connection for correct voltage at the load
- DC-OK signal
- Internal auxiliary voltage, Stand-by 5 V/0.3A
- Conforms to EN 60601-1
