MEAN WELL RSDW20G-05 DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 32.76 / piece)
€ 32.76
plus VAT.
Only 2 Piece(s) available
Highlights & Details
MEANWELL DC/DC converter module series RSDW20 DIP/DIL 2"x1" Case Single Output input voltage ratio: 4:1 Power: 20W Railway
- In the DIP/DIL 2 x 1 inch housing
- For direct PCB mounting
- Input voltage range 4:1
- No minimum load required
- Input/output insulation 1500 V DC
- Protection: short circuit (continuously), overload, over voltage and input voltage
- Efficiency up to 90%
- This text is machine translated.
Technical specifications
- Product type
DC/DC converter
- Type
RSDW20G-05
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Max. output current
4 A
- Output current (max.) - rounded
4 A
- Efficiency (max.)
89 %
20 W
- Insulation voltage
1500 V DC
- Connection
Pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+85 °C
- Dim
(L x W x H) 50.8 x 25.4 x 10.2 mm
- Height
10.2 mm
- Length
50.8 mm
- Width
25.4 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5 V DC
- Weight
35 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2143365 MEAN WELL RSDW20G-05 DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2143365 MEAN WELL RSDW20G-05 DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2143365 MEAN WELL RSDW20G-05 DC/DC converter 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Description
Features
- In the DIP/DIL 2 x 1 inch housing
- For direct PCB mounting
- Input voltage range 4:1
- No minimum load required
- Input/output insulation 1500 V DC
- Protection: short circuit (continuously), overload, over voltage and input voltage
