Metrel MD 9060 SN Handheld multimeter Digital CAT IV 1000 V Display (counts): 500000
EAN:
Part number:
Item no:
Number
Total (€ 368.91 / piece)
€
Only 3 Piece(s) available
Highlights & Details
Digital Multimeter MD 9060
- CAT IV 1000 V
- Dc and AC voltage measurement TRMS
- Ac and DC current measurement TRMS
Technical specifications
- Voltage reading range DC (min.)
0.01 mV
- Product type
Handheld multimeter
- Voltage DC reading range (max.)
1000 V
- V AC reading range (min.)
0.01 mV
- V AC reading range (max.)
1000 V
- Amperage reading range DC (min.)
0.01 µA
- A DC reading range (max.)
10 A
- A AC reading range (min.)
0.01 µA
- Amperage reading range AC (max.)
10 A
- Reading range - resistance
0.01 Ω - 50 MΩ
- Reading range - capacity
0.01 nF - 25 mF
- Frequency reading range
5 Hz - 1 MHz
- DC resistance
10 MΩ
- AC resistance
10 MΩ
- Basic accuracy
0.08 %
- Measurement type (details)
True RMS
- Frequency range
20 Hz -100 kHz Hz
- Interfaces
optical
- Power supply (details)
9V block battery
- Height
208 mm
- Width
103 mm
- Weight
635 g
Manufacturer's standards (no certificate)
- Reading category
CAT IV 1000 V
- Voltage metering
AC/DC
- Current reading
AC/DC
- Type
MD 9060 SN
- Display
Digital
- Display (counts)
500000
- Dim
(W x H) 103 mm x 208 mm
- Temperature reading range (max.)
+1000 °C
- Temperature reading range (min.)
-50 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 358517 Metrel MD 9060 SN Handheld multimeter Digital CAT IV 1000 V Display (counts): 500000
Description
The MD9060 is equipped with an integrated frequency converter function for the measurement of real values as a function of the frequency. Other features are a large two-line LC-Display, fast data acquisition and transfer (via optical interface), CAT IV / 1000 V, voltage and current measurement TRMS, conductivity measurement and fast one-handed operation. To the many additional functions of the MD 9060 include data hold function, memory function, Min/Max, mean value, differential, tip, Tip/tip with particularly short response time (1 ms), automatic cut-off, frequency filter, reset and relative function. The MD9060 is the device of choice for demanding measurements in industry, laboratory, repair workshops and maintenance.
This text is machine translated.
This text is machine translated.
Features
- Dc and AC voltage measurement TRMS
- Ac and DC current measurement TRMS
- Capacitance testing
- Resistance measurement
- Diode testing
- Measurement of the power frequency
- Measure the frequency of digital signals
- Continuity testing
- (Acoustic signalling)
- Conductivity measurement
- Temperature reading
- TRMS: Exact display sinusoidal and non-sinusoidal signals
- VFD: function for measuring frequency dependence of the true values
- Auto Range: switchable between automatic and manual measuring range selection
- Temperature measurement: Measurement of temperatures T1, T2 and T1 + T2 in Celsius and Fahrenheit
- Cable alarm: Warning when test leads are connected incorrectly
- Relative measurement: Measurement of the difference between two signals or remove the background noise
- MAX/MIN/AVG: recording of maximum, minimum and average values
- Data Hold function: Data Hold function for freezing the display for later analysis
- Peak value storage: peak detection (peak value of moment power)
- PC Link: Download the measurement results to the computer with the optional PC-Software
- Security: Surge Protection CAT IV / 1000 V
- Background lighting: large and bright two-line LC-Display with 3-5/6 Digits
- Up to 500,000 with background illumination for working in low light.
Scope of delivery
- Test lead, black/red
- Temperature sensor type K
- Battery, 1 x 9 V Block
- User manual
Hints
Software is necessary for reading (AMD 9050)
System requirements
- Windows ® XP/7 or later
