Stroke drawing/circuit diagram
Molex Socket housing cable Total number of pins 3 Contact spacing: 2.5 mm 22011032 1 pc(s) Bag
Product type
Socket housing cable
Connector type
Socket
No. of rows
1
CS
2.5 mm
Total number of pins
3
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 0.04 / piece)
€ 0.04
incl. VAT
14-day return policy included
Highlights & Details
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 3
Our service for you
Technical specifications
- Please review product datasheet for further information.
- Packaging type
Bag
- Product type
Socket housing cable
- Connector type
Socket
- No. of rows
1
- CS
2.5 mm
- Total number of pins
3
- Content
1 pc(s)
- Case material
Nylon (NL)
- Manufacturer part #
22011032
- Factory colour
Ecru
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-40 °C
- Type
Molex MOL Power & Signal Sol.
- Engineering Part No
5051-03
- Engineering Series Name
2.5MM W/B HSG
- Engineering Series No
05051
Documents & Downloads
Datasheet
Datasheet 2447767 Molex Socket housing cable Total number of pins 3 Contact spacing: 2.5 mm 22011032 1 pc(s) Bag
User & Safety Instructions
User & Safety Instructions 2447767 Molex Socket housing cable Total number of pins 3 Contact spacing: 2.5 mm 22011032 1 pc(s) Bag
Circuit diagramm
Circuit diagramm 2447767 Molex Socket housing cable Total number of pins 3 Contact spacing: 2.5 mm 22011032 1 pc(s) Bag
Description
2.50mm Pitch KK Wire-to-Board Housing, Female, Friction Lock, for 2759/5159 Crimp Terminals, 3 Circuits
