Image similar
Image similar
Panasonic AQW212EH PhotoMOS Relay AQW212EH N/A N/A 500 mA
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 6.71
5
6% = € 0.41
€ 6.30
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 6.71 / piece)
€
Highlights & Details
Panasonic AQW212EH PhotoMOS Relay AQW212EH N/A N/A 500 mA
- Ideal for telecommunications, PC, security equipment and sensors.
- 8-pin type, miniature design.
Technical specifications
- ON resistance 0.83 Ω
- Type
AQW212EH
- Contact type
2 makers
- Enclosure
DIP 8
- Connection
Print
- Number of pins
8
- R(on) (max.)
2.5 Ω
- Switching voltage (max.)
60 V DC
60 V AC
- Switching current (max.)
500 mA
- Power dissipation
850 mW
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Dim
- Content
1 pc(s)
- RoHS-compliant
- Switching current
500 mA
- Type
AQW212EH
- Max. permanent current
500 mA
- Insulation voltage
5 kV
- Temperature range
-40 - +80 °C
- Product type
PhotoMOS relay
Documents & Downloads
Datasheet
Datasheet 504886 Panasonic AQW212EH PhotoMOS Relay AQW212EH N/A N/A 500 mA
Description
Two-channel PhotoMOS relay in compact DIP casing Application: telecommunication, measurement, security and medical technology, input and output modules, remote monitoring systems.
Hints
Approvals: UL, CSA, BSI.
