Name: Phoenix Contact 1935323 Screw terminal 2.50 mm² Number of pins 3 Green 1 pc(s)
Brand: Phoenix Contact
SKU: 744359
Availability: BackOrder

Green, eight-pole terminal block with silver screws, used for electrical connections on printed circuit boards.

Image similar

Product type

Screw terminal

5 mm

Pins per row

Number of pins

Connection

Screw terminal

Datasheet (PDF)

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 3

Total (€ 0.58 / piece)

€ 1.74

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Print- screw terminal block with up to 2.5 mm ² cross cable connection.

Content 1 pc(s)

Technical specifications

Type: PT 1,5/ 3-5,0-V

Product type: Screw terminal

Features: + wire protector
Stackable

CS: 5 mm

No. of rows: 1

Pins per row: 3

Number of pins: 3

Series: PT

Min. stripping length: 5 mm

Stripping length (max.): 5 mm

Connection: Screw terminal
Print

Nominal current: 17.5 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 17.5 A

Cross section (inflexible) (min.): 0.20 mm²

Cross section (flexible) (max.): 2.50 mm²

Cross section (inflexible) (max.): 2.50 mm²

AWG (min.): 26

Connector orientation: Perpendicular (to the PCB)

AWG max.: 14

Contact material: Cathode copper, tin plated

Enclosure material: Polyamide

Factory colour: Green

Wire protection: Yes

Actuation direction: Parallel (to the PCB)

Manufacturer part #: 1935323

Industrial packaging: Yes

Content: 1 pc(s)

Nominal voltage: 400 V

Width: 15.00 mm

Height: 12.50 mm

Length: 11.40 mm

Type: PT 1,5/ 3-5,0-V

Type: Screw connection

Nominal current (details): 16 A

Connector cross section: 2.5 mm²

Pins: 3

Connection: -

Fitting type (details): Solder

Variants(All information include VAT, plus shipping costs)

Pins per row

Number of pins

Connector orientation

Phoenix Contact 1935323 Screw terminal 2.50 mm² Number of pins 3 Green 1 pc(s)

Item no:744359

Available soon

Conrad Electronic

This article

Perpendicular (to the PCB)

Piece(s)

Minimum order quantity: 3

Multiple: 1

€ 0.58^*

Phoenix Contact 1935161 Screw terminal 2.50 mm² Number of pins 2 Green 1 pc(s)

Item no:744153

Fast track dispatch on Thu 15 Oct

231 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 7

Multiple: 1

€ 0.59^*

Phoenix Contact 1935174 Screw terminal 2.50 mm² Number of pins 3 Green 1 pc(s)

Item no:744167

Fast track dispatch on Thu 15 Oct

480 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 5

Multiple: 1

€ 0.82^*

Phoenix Contact 1935187 Screw terminal 2.50 mm² Number of pins 4 Green 1 pc(s)

Item no:744180

Fast track dispatch on Thu 15 Oct

209 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 3

Multiple: 1

€ 1.49^*

Phoenix Contact 1935190 Screw terminal 2.50 mm² Number of pins 5 Green 1 pc(s)

Item no:744194

Fast track dispatch on Thu 15 Oct

16 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 2

Multiple: 1

€ 1.79^*

Phoenix Contact 1935200 Screw terminal 2.50 mm² Number of pins 6 Green 1 pc(s)

Item no:744207

Fast track dispatch on Thu 15 Oct

180 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.49^*

Phoenix Contact 1935213 Screw terminal 2.50 mm² Number of pins 7 Green 1 pc(s)

Item no:744221

Fast track dispatch on Thu 15 Oct

24 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.49^*

Phoenix Contact 1935226 Screw terminal 2.50 mm² Number of pins 8 Green 1 pc(s)

Item no:744233

Fast track dispatch on Thu 15 Oct

2 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.49^*

Phoenix Contact 1935239 Screw terminal 2.50 mm² Number of pins 9 Green 1 pc(s)

Item no:744246

Fast track dispatch on Thu 15 Oct

76 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.99^*

Phoenix Contact 1935242 Screw terminal 2.50 mm² Number of pins 10 Green 1 pc(s)

Item no:744260

Fast track dispatch on Thu 15 Oct

40 Piece(s)Conrad Electronic

Parallel (to the PCB)

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.29^*

Documents & Downloads

Datasheet

Datasheet 744359 Phoenix Contact 1935323 Screw terminal 2.50 mm² Number of pins 3 Green 1 pc(s)

User & Safety Instructions

User & Safety Instructions 744359 Phoenix Contact 1935323 Screw terminal 2.50 mm² Number of pins 3 Green 1 pc(s)

Description

COMBICON terminal blocks with screw terminals up to 2.5 mm.
Large terminal capacity by rectangular terminal space. Highly elastic head protection for problem free, repeated connecting. Robust design with high current capacity. Plus / minus screw. For PT 1.5/...-PVH-5, 0 pin connector PST 1.3/...-5.0 is required. Connection direction vertical to the printed circuit board, with dowel joint housing.
