Phoenix Contact Pin housing PCB MSTBV Total number of pins 4 Contact spacing: 5 mm 1753479 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
3
-
€ 1.25
5
2% = € 0.03
€ 1.22
10
5% = € 0.06
€ 1.19
50
10% = € 0.12
€ 1.13
100
20% = € 0.25
€ 1.00
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 3
Total (€ 1.25 / piece)
€
Highlights & Details
Single storeyed basic case for für wave soldering processes
- Content: 1 ST
- This text is machine translated.
Technical specifications
- Pin dimensions: 1 x 1 mm
- Insulation material group: IIIa
- Insulation material type: PBT.
- Connector type
Pin strip, straight
- Connector system
wire-to-board
- Series
MSTBV
- Features
lateral opening
- CS
5 mm
- Pins per row
4
- Total number of pins
4
- Pin Ø
1.4 mm
- Pin shape
Rectangular
- Nominal current
12 A
- Nominal current - rounded value
12 A
- Content
1 pc(s)
- Dim
(L x W x H) 8.60 x 20.00 x 15.90 mm
- Factory colour
Green
- Height
15.90 mm
- Length
8.60 mm
- Width
20.00 mm
- Industrial packaging
Yes
- Connection
Print
- Connector contact surface
Tin plated
- Board contact surface
Tin plated
- Actuation direction
Perpendicular (to the PCB)
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
1753479
- Type
MSTBV 2,5/ 4-G
- Type
Combicon basic housing
- Nominal voltage
320 V
- Min. stripping length
5.00 mm
- Nominal current (details)
12 A
- No. of rows
1
- Contamination level
3
- Contact material
Cathode copper
- Case material
Polyamide
- RoHS-compliant
- Product type
Pin housing PCB
Documents & Downloads
Datasheet
Datasheet 743463 Phoenix Contact Pin housing PCB MSTBV Total number of pins 4 Contact spacing: 5 mm 1753479 1 pc(s)
User & Safety Instructions
User & Safety Instructions 743463 Phoenix Contact Pin housing PCB MSTBV Total number of pins 4 Contact spacing: 5 mm 1753479 1 pc(s)
Description
Suitable PCB connection technology for order no. 74 34 35
