Image similar
Phoenix Contact Pin housing PCB PC Total number of pins 3 Contact spacing: 7.62 mm 1804807 50 pc(s)
Product type
Pin housing PCB
Connector type
Plug, horizontal mount
No. of rows
1
Series
PC
CS
7.62 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 2.50 / piece)
€ 124.99
incl. VAT
14-day return policy included
Highlights & Details
Base strip PC 4/ 3-G-7,62
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 3
Technical specifications
- Product type
Pin housing PCB
- Connector type
Plug, horizontal mount
- No. of rows
1
- Connector system
wire-to-board
- Series
PC
- CS
7.62 mm
- Pins per row
3
- Total number of pins
3
- Width
29.00 mm
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Content
50 pc(s)
- Dim
(L x W x H) 20.00 x 29.00 x 22.84 mm
- Connection
Print
- Manufacturer part #
1804807
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Nominal voltage
630 V
- Height
22.84 mm
- Length
20.00 mm
- Connector orientation
Parallel (to the PCB)
- Type
PC 4/ 3-G-7,62
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 194357 Phoenix Contact Pin housing PCB PC Total number of pins 3 Contact spacing: 7.62 mm 1804807 50 pc(s)
User & Safety Instructions
User & Safety Instructions 194357 Phoenix Contact Pin housing PCB PC Total number of pins 3 Contact spacing: 7.62 mm 1804807 50 pc(s)
Description
Header, Nominal current: 20 A, Rated voltage (III/2): 630 V, Number of positions: 3, Pitch: 7.62 mm, Color: green, Contact surface: Tin, Assembly: Soldering, Mounting flange: Accessory Order No. 1827570
