Image similar
Phoenix Contact Socket housing cable FKC Total number of pins 2 Contact spacing: 5 mm 1942154 50 pc(s)
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
FKC
CS
5 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 1.56 / piece)
€ 77.99
incl. VAT
Only 2 Set(s) available
Highlights & Details
Printed-circuit board connector FKC 2,5 HC/ 2-ST
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 2
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
FKC
- Features
+ push-in spring bracket
- CS
5 mm
- Pins per row
2
- Total number of pins
2
- Width
25.60 mm
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Content
50 pc(s)
- AWG max.
12
- AWG (min.)
24
- Stripping length (max.)
10.00 mm
- Dim
(L x W x H) 10.10 x 25.60 x 15.00 mm
- Connection
Spring-loaded terminal
Plug
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1942154
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
320 V
- Height
15.00 mm
- Length
10.10 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- Type
FKC 2,5 HC/ 2-ST
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 195376 Phoenix Contact Socket housing cable FKC Total number of pins 2 Contact spacing: 5 mm 1942154 50 pc(s)
User & Safety Instructions
User & Safety Instructions 195376 Phoenix Contact Socket housing cable FKC Total number of pins 2 Contact spacing: 5 mm 1942154 50 pc(s)
Description
Plug component, Nominal current: 16 A, Rated voltage (III/2): 320 V, Number of positions: 2, Pitch: 5 mm, Connection method: Spring-cage conn., Color: green, Contact surface: Tin, COMBICON plug-in connectors may only be activated under no load conditions. If for operating reasons small loads must be switched, experimental values are available upon request.
