Name: Phoenix Contact Socket housing cable FRONT-MC Total number of pins 20 Contact spacing: 3.81 mm 1851038 50 pc(s)
Brand: Phoenix Contact
SKU: 773700
Availability: InStock

A green connector with 24 pins, suitable for electronic components.

Image similar

Product type

Socket housing cable

Connector type

Socket, straight

No. of rows

Series

FRONT-MC

3.81 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

5 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 50 pc(s))

Set(s)

Total (€ 20.50 / piece)

€ 1,025.00

incl. VAT

Only 5 Set(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Printed-circuit board connector FRONT-MC 1,5/20-STF-3,81

Content: 50 pc(s)
No. of rows: 1
Total number of pins: 20

Technical specifications

Product type: Socket housing cable

Connector type: Socket, straight

No. of rows: 1

Connector system: wire-to-board

Series: FRONT-MC

CS: 3.81 mm

Pins per row: 20

Total number of pins: 20

Width: 86.59 mm

Nominal current: 8 A

Nominal current - rounded value: 8 A

Content: 50 pc(s)

AWG max.: 16

AWG (min.): 28

Stripping length (max.): 9.00 mm

Dim: (L x W x H) 12.30 x 86.59 x 21.70 mm

Connection: Screw terminal
Plug

Actuation direction: Perpendicular (to the PCB)

Manufacturer part #: 1851038

Factory colour: Green

Industrial packaging: Yes

Contact material: Tin plated

Connector contact surface: Tin plated

Nominal voltage: 160 V

Height: 21.70 mm

Length: 12.30 mm

max. cross section: 1.5 mm²

Min. cross section: 0.14 mm²

Type: FRONT-MC 1,5/20-STF-3,81

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 773700 Phoenix Contact Socket housing cable FRONT-MC Total number of pins 20 Contact spacing: 3.81 mm 1851038 50 pc(s)

User & Safety Instructions

User & Safety Instructions 773700 Phoenix Contact Socket housing cable FRONT-MC Total number of pins 20 Contact spacing: 3.81 mm 1851038 50 pc(s)

Description

Plug component, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 20, Pitch: 3.81 mm, Connection method: Screw connection, Color: green, Contact surface: Tin

Description

Plug component, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 20, Pitch: 3.81 mm, Connection method: Screw connection, Color: green, Contact surface: Tin
