Pin module 09140052646 HARTING Content: 1 pc(s) Pin module
Product type
Pin module
Number of pins
5
Type
09140052646
Manufacturer part #
09140052646
Factory colour
Pebble grey (RAL 7032)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 2
Multiple: 2
Total (€ 33.99 / piece)
€ 33.99
incl. VAT
Only 2 Piece(s) available
Technical specifications
- Net weight: 22.6 g
- Rated current: 70 A
- Number of contacts: 1
- Rated voltage: 1000 V
- Conductor cross-section: 6 mm² - 16 mm²
- Gender: Pin
- Plug-in cycles: ≥ 500
- Tightening torque: 2 Nm - 6 mm², 3 Nm - 10 mm², 4 Nm - 16 mm², 4 Nm - 14 mm²
- Rated surge voltage: 8 kV
- Rated surge voltage control: 6 kV
- Forward resistance: ≤ 0.5 mΩ
- Wire stripping length: 11 mm - 12 mm
- Pollution degree: 3
- additional contacts: + 4 additional control contacts
- Rated current Control: 16 A
- Rated voltage Control: 400 V
- Type
09140052646
- Product type
Pin module
- Manufacturer part #
09140052646
- Factory colour
Pebble grey (RAL 7032)
- Number of pins
5
- Connection
Axial screw terminal
Crimp
- Total no. of pins
5
- Content
1 pc(s)
- Material
Polycarbonate (PC)
- Max. temperature
+125 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1989675 Pin module 09140052646 HARTING Content: 1 pc(s) Pin module
User & Safety Instructions
User & Safety Instructions 1989675 Pin module 09140052646 HARTING Content: 1 pc(s) Pin module
