Name: Pressol 17 610 Lubrication system 125 cm³ Suitable for (lubricants) 10 kg grease buckets mechanical
Brand: Pressol
SKU: 2621849
Availability: BackOrder

Metal high-pressure grease gun with long hose and handle, used for maintenance or lubrication of machinery.

EAN:

Part number:

Item no:

Dispatches on Mon 16 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 169.99 / piece)

€ 169.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Container type: Gebinde

Product type: Lubrication system

Max. feed rate: 30 cm³

Operation type: mechanical

Capacity: 125 cm³

Material: Steel

Content: 1 pc(s)

Operating pressure: 550 bar

Suitable for: 10 kg grease buckets

Length: 1500 mm

Features: incl. mouthpiece

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2621849 Pressol 17 610 Lubrication system 125 cm³ Suitable for (lubricants) 10 kg grease buckets mechanical

Features

Hand pump for filling the one-hand grease gunPump unitSuction pipeDust cover (17 171), container mounting (17 197) and grease pusher (17 230)One-hand grease gun (EHFP), connection M 10 x 1 (17 600)Nozzle tube, straight, M 10 x 1, 150 mm (12 435)Mouthpiece, 4 BA, M 10 x 1 (12 631)Delivery hose (17 003)Conveying media greases up to NLGI 2Delivery volume for filling the grease gun / stroke (cm³): 30Hose length (mm): 1500Grease feed into the one-hand grease gun: Using the hand leverGrease pusher for 10 kg containerØ Grease pusher (mm) 210 – 240Length of suction tube (mm) 510Hose / single hand grease gun connection: Rectus quick coupler, type 26 (17 601), with check valveDelivery volume EHFP/stroke (cm³): 0.4Discharge pressure up to (bar) 550Bursting pressure EHFP (bar) 850Burst load grease gun head (bar): 1200Filling volume EHFP (cm³): 125Grease gun connection on pressure side: M 10 x 1Operation of the grease pump piston: Manually using the pressure handlePump body material: SteelPump head material: Impact-resistant die-cast zincSurface treatment: All parts made of steel are galvanized
This text is machine translated.

Related products can be found here

Cleaning Cloth, Wipes Lubricants & Grease

Description

Features

Hand pump for filling the one-hand grease gunPump unitSuction pipeDust cover (17 171), container mounting (17 197) and grease pusher (17 230)One-hand grease gun (EHFP), connection M 10 x 1 (17 600)Nozzle tube, straight, M 10 x 1, 150 mm (12 435)Mouthpiece, 4 BA, M 10 x 1 (12 631)Delivery hose (17 003)Conveying media greases up to NLGI 2Delivery volume for filling the grease gun / stroke (cm³): 30Hose length (mm): 1500Grease feed into the one-hand grease gun: Using the hand leverGrease pusher for 10 kg containerØ Grease pusher (mm) 210 – 240Length of suction tube (mm) 510Hose / single hand grease gun connection: Rectus quick coupler, type 26 (17 601), with check valveDelivery volume EHFP/stroke (cm³): 0.4Discharge pressure up to (bar) 550Bursting pressure EHFP (bar) 850Burst load grease gun head (bar): 1200Filling volume EHFP (cm³): 125Grease gun connection on pressure side: M 10 x 1Operation of the grease pump piston: Manually using the pressure handlePump body material: SteelPump head material: Impact-resistant die-cast zincSurface treatment: All parts made of steel are galvanized
This text is machine translated.
