Schneider Electric METSECTLV1010U METSECTLV1010U Cable current transformer Primary current 100 A Line feed-through (H x
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 83.99 / piece)
€ 83.99
incl. VAT
14-day return policy included
Highlights & Details
Cable conversion transformer LVCT 100 A - 0.333 V output, diameter 16 x 16 mm
- Input current (current) 100 A
Technical specifications
- Product type
Cable current transformer
- Primary current
100 A
- Type
METSECTLV1010U
- Dim
(L x W x H) 53 x 41 x 31 mm
- Input current
100 A
- Line feed-through (W)
16 mm
- Line feed-through (H x W)
16 x 16 mm
- Line feed-through (H)
16 mm
- Width
41 mm
- Height
31 mm
- Length
53 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3755385 Schneider Electric METSECTLV1010U METSECTLV1010U Cable current transformer Primary current 100 A Line feed-through (H x
User & Safety Instructions
User & Safety Instructions 3755385 Schneider Electric METSECTLV1010U METSECTLV1010U Cable current transformer Primary current 100 A Line feed-through (H x
Description
This low voltage transformer LVCT is a cable converter for PowerLogic EM4235, EM3570X, Acti 9 iEM3455, iEM3465 and ION9000. Ideal for retrofitting Schneider Electric energy meters and power analyzers that accept a low voltage transformer input LVCT. The converter is appropriate for a circuit of 100 A. 0.333 V output, (Size AAA). Dimensions 53 x 41 x 31 mm, inner dimensions 16 x 16 mm, rated current IPN 100 A. Accuracy class 1 in accordance with IEC 61869-2. Frequency range 50/60 Hz. Length of feed line 1.8 m.
This text is machine translated.
This text is machine translated.
