SCI R9-3612, GREEN LED indicator light Green 2.1 V - 20 mA 45 mcd
Product type
LED indicator light
Forward voltage U(F)
2.1 V
Forward current I(F)
20 mA
Recess diameter
6.2 mm
Light intensity I(V)
45 mcd
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 1.49 / piece)
€ 1.49
incl. VAT
14-day return policy included
Highlights & Details
SCI R9-3612, GREEN LED indicator light Green 2.1 V - 20 mA 45 mcd
Our service for you
Technical specifications
- Lens: diffuse
- Product type
LED indicator light
- Type
R9-3612, GREEN
- Factory colour
Green
- Forward voltage U(F)
2.1 V
- Forward current I(F)
20 mA
- Recess diameter
6.2 mm
- Front panel thickness
max. 3.5 mm
- Case colour
Chrome
- Material
Brass
Phenol
- Material properties
shiny
- Mounting type
Screw
- Light intensity I(V)
45 mcd
- Radiation angle
50°
- LED features
External reflector
LED 3 mm
- Connection
Soldering
- Min. temperature
-25 °C
- Max. temperature
85 °C
- RoHS-compliant
Yes
- Type
3 mm LED-outer reflector
- Content
1 pc(s)
- Material (details)
Chrome-plated brass / Phenol
- Operating current
-
- Operating temperature
-25 - +85 °C
- Operating voltage
-
