Name: Siemens 3RV2011-1DA20 Circuit breaker 1 pc(s) Adjustment range (amperage): 2.2 - 3.2 A Switching voltage (max.): 690 V A
Brand: Siemens
SKU: 1741879
Availability: InStock

Siemens Sirius electrical switch in a grey housing, with 'ON' print. Used for controlling electrical devices.

An industrial system with open circuits is prominent in the foreground. Behind it, a window with raindrops looks out over machines.

'Mountable Accessories for Circuit Breakers' shows components and connections such as auxiliary switches, voltage transformers and disconnectors with labels.

'Circuit diagram of a three-phase circuit breaker with terminals 1/L1, 3/L2, 5/L3 at the top and 2/T1, 4/T2, 6/T3 at the bottom.'

Technical drawing of an electrical switch with dimensions. Left: front view with labels, right: side view. Dimensions: 45mm wide, 106mm high, 96.9mm deep.

Switching device with rotary switch, Siemens Sirius, indicates positions 'ON', 'OFF' and 'TRIPPED'.

1/6

Image similar

Product type

Circuit breaker

Amperage adjustment range (max.)

3.2 A

Connection

Spring-loaded connector

Type

3RV2011-1DA20

Type

S00

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 67.99 / piece)

€ 67.99

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Continuous current: 3.2 A
Mechanical life of main contacts: 100,000 switching cycles
Max. Conductor cross-section (solid or stranded): 4 mm²
Max. Conductor cross-section (fine): 2.5 mm²

Product type: Circuit breaker

Type: 3RV2011-1DA20

Type: S00

Amperage adjustment range (min.): 2.2 A

Amperage adjustment range (max.): 3.2 A

Adjustment range (amperage): 2.2 - 3.2 A

No. of pins: 3-pin

Switching voltage (max.): 690 V AC

Compatible with series: Siemens Sirius series

Compatible with: Siemens

Mounting type: Snap-in
Screw-fit

Min. temperature: -20 °C

Max. temperature: +60 °C

Features: + auxiliary contact

Connection: Spring-loaded connector

: IP20

Depth: 97 mm

Width: 45 mm

Height: 106 mm

Dim: (W x H x D) 45 x 106 x 97 mm

Content: 1 pc(s)

RoHS-compliant: Yes

Factory colour: Multicolour

: 45

: 106 mm

: 97 mm

: 1.1 kW

: FALSE

: 3.2 A

: FALSE

: 3

: 690-690 V

: 2.2-3.2 A

: IP20

: TRUE

: Spring clamp connection

: Turn button

: Magnetic

: 0.6 kW

: 100 kA

: TRUE

: Built-in device fixed built-in technique

UKCA: yes
