Name: Siemens 3RV2311-0HC20 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 45 x 106 x 97 mm
Brand: Siemens
SKU: 1747075
Availability: BackOrder

A grey Siemens SIRIUS switch for industrial applications, showing the position between 'I' (on) and 'O' (off).

An open electrical cabinet reveals wired components, while rain trickles down a window outside. A machine can be seen in the background.

'Diagram shows mounting accessories for circuit breakers: Transverse auxiliary switch, lateral auxiliary switch, signalling switch, isolating distance holder and terminal blocks.'

A circuit diagram with a transformer 'T', which distributes voltage to three loads 'L1', 'L2', and 'L3'. Markings: '1/L1', '3/L2', '5/L3', '2/T1', '4/T2', '6/T3'.

'Siemens switching device: Main switch in the centre with OFF and ON positions.'

1/6

Image similar

Product type

Circuit breaker

Connection

Spring-loaded connector

Type

3RV2311-0HC20

Type

S00

No. of pins

3-pin

Datasheet (PDF)

Dispatches on Fri 23 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 97.99 / piece)

€ 97.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Continuous current: 0.8 A
Mechanical life of main contacts: 100,000 switching cycles
Max. Conductor cross-section (solid or stranded): 4 mm²
Max. Conductor cross-section (fine): 2.5 mm²

Product type: Circuit breaker

Type: 3RV2311-0HC20

Type: S00

No. of pins: 3-pin

Switching voltage (max.): 690 V AC

Mounting type: Snap-in
Screw-fit

Min. temperature: -20 °C

Max. temperature: +60 °C

Connection: Spring-loaded connector

: IP20

Depth: 97 mm

Width: 45 mm

Height: 106 mm

Dim: (W x H x D) 45 x 106 x 97 mm

Content: 1 pc(s)

RoHS-compliant: Yes

: 45

: 106 mm

: 97 mm

: 0.2 kW

: FALSE

: 0.8 A

: FALSE

: 3

: IP20

: FALSE

: Spring clamp connection

: Turn button

: Magnetic

: 0.1 kW

: 100 kA

: FALSE

: Built-in device fixed built-in technique

UKCA: yes
