Name: Siemens 3SK1111-2AB30 3SK11112AB30 Circuit protection 24 V DC, 24 V AC Nominal current 5 A
Brand: Siemens
SKU: 1419967
Availability: InStock

Siemens industrial automation module, Sirius model, with yellow safety marking, marked areas 'Failsafe', 'Device', 'Out'.

Several interconnected electrical switchgear with blue cables are mounted in a control cabinet.

Siemens 3SK1111-2AB30 3SK11112AB30 Circuit protection 24 V DC, 24 V AC Nominal current 5 A-2

Circuit diagram of a safety relay: On the left, various inputs to the logic (T1 to T4, IN1 to IN3), on the right output relays (13-14, 23-24, 33-34).

Technical drawing of an electrical component with dimensions: width 22.5 mm, height 100 mm, depth 121.7 mm. Marking 'SIRIUS'.

Diagram of a Siemens SIRIUS device with connection points. Shows labels for Failsafe, Device and Out, along with Start and Auto buttons.

1/6

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Tue 27 Oct

5 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 239.99 / piece)

€ 239.99

incl. VAT

Only 5 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Overvoltage category:3; insulation voltage rated value: 300 V; Control Supply Voltage Frequency: 50/60 Hz

Product type: Circuit protection

Supply current: 5 A

Operating voltage: 24 V DC/AC

Nominal voltage: 24 V DC
24 V AC

Type: Spring-loaded connection

Manufacturer part #: 3SK11112AB30

Nominal current: 5 A

Nominal current - rounded value: 5 A

Type: 3SK1111-2AB30

Dim: (L x W x H) 121.6 x 22.5 x 100 mm

Connection: Spring-loaded connector

Width: 22.5 mm

Height: 100 mm

Length: 121.6 mm

Depth: 121.6 mm

Max. temperature: 60 °C

Min. temperature: -25 °C

: IP20

Connector: Push-in terminal

Weight: 260 g

: 22.5

: Other

: 100 mm

: 121.6 mm

: TRUE

: FALSE

: TRUE

: TRUE

: 3

: 0

: 1

: 0

: Spring clamp connection

: FALSE

: FALSE

: TRUE

: TRUE

: TRUE

: TRUE

: Level e

: 0

: AC/DC

: One- and two-channel

: 3

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1419967 Siemens 3SK1111-2AB30 3SK11112AB30 Circuit protection 24 V DC, 24 V AC Nominal current 5 A

User & Safety Instructions

User & Safety Instructions 1419967 Siemens 3SK1111-2AB30 3SK11112AB30 Circuit protection 24 V DC, 24 V AC Nominal current 5 A

Description

SIRIUS safety relay basic device standard series relay release circuits 3 NO plus relay signaling circuit 1 NC US = 24 V AC/DC spring connection (push-in) SIRIUS 3SK1 safety relay for self-contained safety applications.
The standard 3SK111 basic units feature simple and variable functionality, providing an economical entry into the world of safety relays. They are Ideal suitable for safety functions with only a few sensors and few enabling circuits. These devices have extensive, worldwide approvals and are thus best suited for global use and export.
The devices are available as 24 V version or with wide-range voltage range, relay or semi-conductor outputs, as well as continuous with screw or spring connection (push-in).
Wide range of accessories such as sealing covers, plug-in lugs for wall mounting and coding pins simplify the handling.
The 3SK safety relays replace the tried and tested 3TK28 series.
Safety is a SIRIUS business.

This text is machine translated.
