Sunset PX 85 Polycrystalline solar panel 85 Wp 12 V
EAN:
Part number:
Item no:
Total (€ 149.99 / piece)
€ 460.00
-67 %
€ 149.99
incl. VAT
14-day return policy included
Highlights & Details
Polycrystalline Solar module
- High performance and quality
- Hardened solar glass
- Anodised aluminum profile
Technical specifications
- Cable cross section 4 mm².
- Protection class IP54
- Cable gland PG16
- Product type
Polycrystalline solar panel
85 Wp
- Nominal voltage
12 V
- Dim
(L x W x H) 1190 x 520 x 35 mm
- Efficiency
19 %
- Connector
Junction box
- Weight
7.5 kg
- Short-circuit current
5290 mA
- Open circuit voltage (OCV)
22.3 V
- Nominal current
4670 mA
- Width
520 mm
- Height
35 mm
- Length
1190 mm
- Voltage (max.)
18.2 V
- Type
PX 85, 12 V polycrystalline
- No. of cells
76
- Module height
35 mm
- Module length
1190 mm
- Module width
520 mm
- Module power (max.)
85 Wp
85 Wp
- Short circuit current
5.50 A
- Idle voltage
21.5 V
- Nominal voltage (details)
17.5 V
- Nominal current (details)
4.85 A
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 110258 Sunset PX 85 Polycrystalline solar panel 85 Wp 12 V
Information
Information 110258 Sunset PX 85 Polycrystalline solar panel 85 Wp 12 V
Description
The keenly priced polycrystalline PX solar module is characterised by particularly high power output. The light background of the cells and the anodised aluminium frame present a neat appearance. The front cover is made from special hardened solar glass, which is bonded into a single unit with the laminate and then surrounded with a warp-resistant aluminium frame. This proven module construction protects the solar cells from moisture ingress, offers high UV stability and also allows the modules to thermally expand.
Features
- High-efficiency polycrystalline silicon solar cells
- Structured cells surface
- Robust and durable
- UV stability
- EVA plastic
- Hardened solar glass
- Warp resistant module frame made of anodized aluminum profile
- Weather-proof junction box
Scope of delivery
- Solar module
- Junction box
- User manual.
Hints
Subject to technical changes. Similar to the illustration.
