Name: TP-LINK TL-SG1005P TL-SG1005P Network switch 5 ports 1 GBit/s PoE
Brand: TP-LINK
SKU: 1629386
Availability: InStock

'TP-Link 5-Port Gigabit Desktop Switch with 4 PoE Ports, Model TL-SG1005P. Displays five Ethernet ports and LED indicators for Power and PoE.'

Five-port Gigabit desktop switch from TP-Link with four PoE ports. Front shows network connections and status indicators.

A 5-port Gigabit desktop switch with 4 PoE ports, model TL-SG1005P, suitable for small networks to connect multiple devices.

'TP-Link 5-Port Gigabit Desktop Switch with PoE', packaging displays product image and text details of performance, with 4 PoE ports highlighted.

A smiling man sits on a sofa with a laptop, whilst advertising text reads 'New Year New Network 2021' and network devices are displayed.

1/6

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

131 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 37.99 / piece)

€ 37.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

TP-LINK TL-SG1005P 5-port 10/100/1000Mbit/s desktop switch with 4 PoE ports

5 x 10/100/1000Mbit/s-RJ45 ports
Four PoE ports, data transfer and power supply only via a cable
Preserves IEEE 802.3af devices and extends your existing network at home or in office
Smooth data transfer thanks to 802.1p/DSCP QoS
Supports PoE with up to 30W per PoE-port
PoE total power of 65W
No configuration or installation is required

Technical specifications

Product type: Network switch

Transfer rate: 1 GBit/s

IEEE 802.3af PoE: 4 x

10/100 Mbps ports: 5 x

10/100/1000 Mbps ports: 5 x

Router features: PoE

Power supply (LOV): mains-powered

MAC addresses: 2000

Weight: 0.87 kg

Width: 99.8 mm

Height: 25 mm

Depth: 98 mm

Type: TL-SG1005P

Interfaces: RJ45

Factory colour: Multicolour

Port: 5 ports

Length: 150 cm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1629386 TP-LINK TL-SG1005P TL-SG1005P Network switch 5 ports 1 GBit/s PoE

User & Safety Instructions

User & Safety Instructions 1629386 TP-LINK TL-SG1005P TL-SG1005P Network switch 5 ports 1 GBit/s PoE

Description

Product Features
The TL-SG1005 P includes five 10/100/1000 Mbit/s ports, four with PoE, and he does not require any configuration or software installation. The device detects and automatically feeds connected PoE-terminals. Thus, both the data transfer as well as the power supply via a single cable is ensured. The network expansion significantly easier.

Power over Ethernet
Four of the five ports this switches support Power over Ethernet. The device detects and automatically connects via PoE connected terminals.
Overload protection
The TL-SG 1005P has a priority circuit, which protects the system against overload. If the PoE-terminals a total of more than 56 W power request, the devices are low priority is switched off.
Port Priority Function
Priority (Port 1> Port 2,> port 3> Port 4): This is a useful feature protects the system from damage due to overload. If the requested performance 56 W exceeds, Port 4 is switched off. For example, port 1, 2 and 4 claim each 15.4 W (this is the maximum possible power per port). Therefore, the total capacity 46.2 W. Now is Port 3 with 10 W claimed by the Prioritatsunktion Port 4 is switched off. This means that now port 1 and port 2 and port 3 with 10 W each with 15.4 W can be supplied, Port 4 is no power.

Easy to use
The TL-SG 1005P is easy to install and to use. An additional configuration is not necessary. Unauffalligem, elegant design, as well as exceptional performance and with quality, the TL-SG 1005P perfectly suitable for each zuhaue or office.

This text is machine translated.
