TracoPower PHV 12-350S10P DC/DC converter (print) 10 mA 3.5 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 360.50 / piece)
€ 360.50
plus VAT.
Highlights & Details
DC/DC high-voltage converter, PHV-Series
- Positive or negative output voltages
- Excellent stability of the output voltage
- High temperature stability
- Shielded metal casing
- Adjustable output voltage:
- This text is machine translated.
Technical specifications
- Product type
DC/DC converter (print)
- Type
PHV 12-350S10P
- Min. input voltage
10.8 V DC
- Input voltage (max.)
16.5 V DC
- No. of outputs
1 x
- Max. output current
10 mA
- Output current (max.) - rounded
10 mA
- Efficiency (max.)
60 %
3.5 W
- Insulation voltage
0 V
- Connection
Solder pins
- PSU features
Adjustable voltage output
- Operating temperature (min.)
-10 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 40 x 60 x 31 mm
- Height
31 mm
- Length
40 mm
- Width
60 mm
- Output voltage (max.)
350 V DC
- Output voltage (min.)
0 V DC
- Output current (min.)
0 mA
- Weight
65 g
- Content
1 pc(s)
- Type
12-350 PHV S10P
