TracoPower TEL 10-4823WI DC/DC converter (print) 48 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 31.92
30
4% = € 1.38
€ 30.54
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 31.92 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEL 10-4823WI
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Max. output current
333 mA
- Output current (max.) - rounded
333 mA
- Efficiency (max.)
87 %
10 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 16
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+88 °C
- Dim
(L x W x H) 23.8 x 13.7 x 11.8 mm
- Height
11.8 mm
- Length
23.8 mm
- Width
13.7 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Weight
6.5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3371933 TracoPower TEL 10-4823WI DC/DC converter (print) 48 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3371933 TracoPower TEL 10-4823WI DC/DC converter (print) 48 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3371933 TracoPower TEL 10-4823WI DC/DC converter (print) 48 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3371933 TracoPower TEL 10-4823WI DC/DC converter (print) 48 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Description
4:1 input range, compact DIL-16 metal housing. Regulated output, E/A-insulation 1500 V/DC. Protection against permanent short circuit, input filter according to EN 55032, class A.
