TracoPower TEL 12-1215 DC/DC converter 24 V DC 0.5 A 12 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 30.99 / piece)
€ 309.90
incl. VAT
14-day return policy included
Highlights & Details
DC DC Converters
- Output 24 V DC / 0.5 A
- Power 12 W
- Solder pins
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
18.0 V DC
- Max. output current
0.5 A
- Output current (max.) - rounded
500 mA
- Min. input voltage
9.0 V DC
- Dim
(L x W x H) 23.8 x 13.7 x 14.0 mm
- Output voltage (max.)
24 V DC
- Connection
Solder pins
12 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
88 °C
- Operating temperature (min.)
-40 °C
- Weight
8.6 g
- Width
13.7 mm
- Height
14.0 mm
- Length
23.8 mm
- Type
TEL 12-1215
