TracoPower TEL 5-1210 DC/DC converter (print) 12 V DC 3.3 V DC 1.2 A 6 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 23.99 / piece)
€ 23.99
incl. VAT
14-day return policy included
Highlights & Details
DC/DC converter TEL 5 series, 6 W, DIL-24
- 3-year guarantee
Technical specifications
- Ripple: (20 MHz bandwidth) 75 mVpp
- Power control ± 0.3%
- Load regulation (%): (Single) ± 1 %/(Dual) 2%
- Product type
DC/DC converter (print)
- Type
TEL 5-1210
- Nominal voltage
12 V DC
- Min. input voltage
10.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
1.2 A
- Output current (max.) - rounded
1.2 A
- Efficiency (max.)
84 %
6 W
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
71 °C
- Dim
(L x W x H) 32.0 x 20.3 x 10.2 mm
- Height
10.2 mm
- Length
32.0 mm
- Width
20.3 mm
- Content
1 pc(s)
6 W
- Output voltage
3.3 V DC
- Output current (details)
1200 mA
- Type
TEL 5 Series
- Operating temperature
-40 °C - +71 °C
- Mains control
max. ±0.3 %
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 154143 TracoPower TEL 5-1210 DC/DC converter (print) 12 V DC 3.3 V DC 1.2 A 6 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 154143 TracoPower TEL 5-1210 DC/DC converter (print) 12 V DC 3.3 V DC 1.2 A 6 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 154143 TracoPower TEL 5-1210 DC/DC converter (print) 12 V DC 3.3 V DC 1.2 A 6 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154143 TracoPower TEL 5-1210 DC/DC converter (print) 12 V DC 3.3 V DC 1.2 A 6 W No. of outputs: 1 x Content 1 pc(s)
Description
Wide-range input 2:1, EN/IEC 60950, UL/cUL 1950.
Features
- Wide-range input 2:1, EN/IEC 60950, UL/cUL 1950.
