TracoPower TES 5-1211 DC/DC converter (SMD) 12 V DC 5 V DC 1 A 5 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 36.13 / piece)
€ 361.30
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TES 5-1211
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Efficiency (max.)
80 %
5 W
- Insulation voltage
1500 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 33.4 x 10.2 x 25.6 mm
- Height
25.6 mm
- Length
33.4 mm
- Width
10.2 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
14 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370724 TracoPower TES 5-1211 DC/DC converter (SMD) 12 V DC 5 V DC 1 A 5 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370724 TracoPower TES 5-1211 DC/DC converter (SMD) 12 V DC 5 V DC 1 A 5 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370724 TracoPower TES 5-1211 DC/DC converter (SMD) 12 V DC 5 V DC 1 A 5 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370724 TracoPower TES 5-1211 DC/DC converter (SMD) 12 V DC 5 V DC 1 A 5 W No. of outputs: 1 x Content 1 pc(s)
Description
SMD package with low profile, 2:1 input range, input/output insulation 1500 V/DC. High accuracy of pin coplanarity, short-circuit proof.
