TracoPower THB 10-2423 DC/DC converter (print) 24 V DC 5 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 63.86 / piece)
€ 638.60
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
THB 10-2423
- Nominal voltage
24 V DC
- Min. input voltage
2.97 V DC
- Input voltage (max.)
3.63 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
- Max. output current
333 mA
- Output current (max.) - rounded
333 mA
- Efficiency (max.)
82 %
10 W
- Insulation voltage
4000 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 25.4 x 50.8 x 17.08 mm
- Height
17.08 mm
- Length
25.4 mm
- Width
50.8 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
24.5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370732 TracoPower THB 10-2423 DC/DC converter (print) 24 V DC 5 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3370732 TracoPower THB 10-2423 DC/DC converter (print) 24 V DC 5 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370732 TracoPower THB 10-2423 DC/DC converter (print) 24 V DC 5 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370732 TracoPower THB 10-2423 DC/DC converter (print) 24 V DC 5 V DC 333 mA 10 W No. of outputs: 2 x Content 1 pc(s)
Description
E/A-insulation 4000 V/AC designed for 300 V/AC operating voltage, 2 x MOOP medical standard according to IEC/EN 60601-1, 3rd edition, 2:1 input range, input filter according to EN 55022, class A, short-circuit proof.
