TracoPower THI 0513 DC/DC converter (print) 5 V DC 15 V DC 130 mA 2 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 34.45 / piece)
€ 34.45
plus VAT.
Only 9 Piece(s) available
Technical specifications
- Product type
DC/DC converter (print)
- Type
THI 0513
- Nominal voltage
5 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
5.5 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
130 mA
- Output current (max.) - rounded
130 mA
- Efficiency (max.)
64 %
2 W
- Insulation voltage
2500 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 20 x 32 x 14 mm
- Height
14 mm
- Length
20 mm
- Width
32 mm
- Output voltage (max.)
15 V DC
- Output voltage (min.)
15 V DC
- Weight
12.4 g
- Content
1 pc(s)
- Type
THI 0513
Documents & Downloads
Datasheet
Datasheet 1510431 TracoPower THI 0513 DC/DC converter (print) 5 V DC 15 V DC 130 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510431 TracoPower THI 0513 DC/DC converter (print) 5 V DC 15 V DC 130 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510431 TracoPower THI 0513 DC/DC converter (print) 5 V DC 15 V DC 130 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Description
E/A-Insulation test voltage 6000 Vpk. With reinforced insulation according to IEC/EN 60950 and IEC/EN 60601-1 safety standards. Regulated outputs, small coupling capacity, DIL-24 plastic casing.
