TracoPower THI 2412 DC/DC converter (print) 24 V DC 12 V DC 165 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 36.13 / piece)
€
Technical specifications
- Product type
DC/DC converter (print)
- Type
THI 2412
- Nominal voltage
24 V DC
- Min. input voltage
21.6 V DC
- Input voltage (max.)
26.4 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
165 mA
- Output current (max.) - rounded
165 mA
- Efficiency (max.)
63 %
2 W
- Insulation voltage
2500 V AC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 20 x 32 x 14 mm
- Height
14 mm
- Length
20 mm
- Width
32 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
12.4 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370841 TracoPower THI 2412 DC/DC converter (print) 24 V DC 12 V DC 165 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370841 TracoPower THI 2412 DC/DC converter (print) 24 V DC 12 V DC 165 mA 2 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370841 TracoPower THI 2412 DC/DC converter (print) 24 V DC 12 V DC 165 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370841 TracoPower THI 2412 DC/DC converter (print) 24 V DC 12 V DC 165 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Description
E/A-Insulation test voltage 6000 Vpk. With reinforced insulation according to IEC/EN 60950 and IEC/EN 60601-1 safety standards. Regulated outputs, small coupling capacity, DIL-24 plastic casing.
