TracoPower THL 30-2422WI DC/DC converter 12 V DC 1.3 A 30 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 63.99 / piece)
€ 639.90
incl. VAT
14-day return policy included
Highlights & Details
DC/DC converter, THL 30WI-series
- Output 12 V DC / 1.3 A
- Power 30 W
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
36 V DC
- Max. output current
1.3 A
- Output current (max.) - rounded
1.3 A
- Min. input voltage
9 V DC
- Dim
(L x W x H) 25.40 x 25.40 x 10.20 mm
- Output voltage (max.)
12 V DC
30 W
- No. of outputs
2 x
- Type
closed
- Operating temperature (max.)
+60 °C
- Operating temperature (min.)
-40 °C
- Weight
25 g
- Width
25.40 mm
- Height
10.20 mm
- Length
25.40 mm
- Type
THL 30-2422WI
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3373095 TracoPower THL 30-2422WI DC/DC converter 12 V DC 1.3 A 30 W
User & Safety Instructions
User & Safety Instructions 3373095 TracoPower THL 30-2422WI DC/DC converter 12 V DC 1.3 A 30 W
Warranty Terms
Warranty Terms 3373095 TracoPower THL 30-2422WI DC/DC converter 12 V DC 1.3 A 30 W
Description
The series THL 30WI represents the latest TRACO development in the segment of the 30 W DC/DC-converters. This series was developed to achieve an optimum price-performance ratio. Important features are: Encapsulated metal casing (25.4 mm x 25.4 mm) and an integrated filter according to EN 55032, Class A. Other features include a high degree of efficiency of up to 88%, operating temperature range -40°C to +60°C (without power reduction), precisely regulated outputs, and the latest IT safety approval according to UL 62368-1. The widespread standard pinning in the market enables an easy design in many cost-critical applications.
This text is machine translated.
This text is machine translated.
Features
- Ultra compact metal case (25.4 mm x 25.4 mm)
- 4:1 input ranges
- Integrated filter according to EN 55032, class A
- Exactly regulated outputs
- E/A-INSULATION 1500 VDC
- Protection against overload, overvoltage and short circuit
- Remote on/off
Scope of delivery
- 10 pieces
