TracoPower TMDC 20-7225H DC/DC converter 420 mA 20 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 70.58 / piece)
€ 352.90
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter
- Type
TMDC 20-7225H
- Min. input voltage
80 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
2 x
- Max. output current
420 mA
- Output current (max.) - rounded
420 mA
- Efficiency (max.)
87 %
20 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 96.0 x 54.0 x 23.3 mm
- Height
23.3 mm
- Length
96.0 mm
- Width
54.0 mm
- RoHS-compliant
Yes
- Output voltage (max.)
24 V DC
-24 V DC
- Output voltage (min.)
24 V DC
-24 V DC
- Weight
107 g
- Content
1 pc(s)
- UKCA
yes
