TracoPower TML 40124 AC/DC PSU (print) 24 V DC 1.667 A 40 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 93.99 / piece)
€ 939.90
incl. VAT
14-day return policy included
Highlights & Details
AC / DC power supply module TML series, 5 - 30 watts
- Output 24 V DC / 1.667 A
- Power 40 W
- Input voltage 85 - 264 V AC
Technical specifications
- max. 120 - 180 % (foldback)
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
1.667 A
- Output current (max.) - rounded
1.67 A
- Min. input voltage
90 V AC
- Dim
(W x H) 64 mm x 25 mm
- Output voltage (max.)
24 V DC
40 W
- No. of outputs
1 x
- Output voltage 1
24 V
- Output current 1
1667 mA
- Operating temperature
-25 to +60 °C
- Insulation voltage
3000 V AC
- Width
64 mm
- Height
25 mm
- Residual ripple
Max 1.5 %
- Type
TML 40124
- Input voltage
85 - 264 V AC
- Mains control
max. ±0.3 %
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3370034 TracoPower TML 40124 AC/DC PSU (print) 24 V DC 1.667 A 40 W
Datasheet 3370034 TracoPower TML 40124 AC/DC PSU (print) 24 V DC 1.667 A 40 W
User & Safety Instructions
User & Safety Instructions 3370034 TracoPower TML 40124 AC/DC PSU (print) 24 V DC 1.667 A 40 W
Warranty Terms
Warranty Terms 3370034 TracoPower TML 40124 AC/DC PSU (print) 24 V DC 1.667 A 40 W
Description
AC/DC-power supply module in cast plastic casing. Wide-range input for worldwide usage. High degree of efficiency, low noise and low remaining ripple. Short-circuit and overload protection. Radio interference suppression acc. EN 55022, class B and FCC, Level B UL 94V-0. Security in accordance with UL 1950, IEC / EN 60950 3 years warranty.
Hints
Derating >50 °C
