TracoPower TML 40205C AC/DC PSU (print) 5 V DC 4 A 40 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 124.99 / piece)
€ 624.95
incl. VAT
14-day return policy included
Highlights & Details
AC / DC power supply module TML series, 5 - 30 watts
- Output 5 V DC / 4 A
- Power 40 W
- Input voltage 85 - 264 V AC
Technical specifications
- max. 120 - 180 % (foldback)
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
4 A
- Output current (max.) - rounded
4 A
- Min. input voltage
90 V AC
- Dim
(W x H) 64 mm x 33 mm
- Output voltage (max.)
5 V DC
40 W
- No. of outputs
2 x
- Output voltage 1
+5 V
- Output voltage 2
-5 V
- Output current 1
4000 mA
- Output current 2
4000 mA
- Operating temperature
-25 to +60 °C
- Insulation voltage
3000 V AC
- Width
64 mm
- Height
33 mm
- Residual ripple
Max 1.5 %
- Type
TML 40205C
- Input voltage
85 - 264 V AC
- Mains control
max. ±0.3 %
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3370035 TracoPower TML 40205C AC/DC PSU (print) 5 V DC 4 A 40 W
Datasheet 3370035 TracoPower TML 40205C AC/DC PSU (print) 5 V DC 4 A 40 W
User & Safety Instructions
User & Safety Instructions 3370035 TracoPower TML 40205C AC/DC PSU (print) 5 V DC 4 A 40 W
Warranty Terms
Warranty Terms 3370035 TracoPower TML 40205C AC/DC PSU (print) 5 V DC 4 A 40 W
Description
AC/DC-power supply module in cast plastic casing. Wide-range input for worldwide usage. High degree of efficiency, low noise and low remaining ripple. Short-circuit and overload protection. Radio interference suppression acc. EN 55022, class B and FCC, Level B UL 94V-0. Security in accordance with UL 1950, IEC / EN 60950 3 years warranty.
Hints
Derating >50 °C
