TracoPower TMR 0512 DC/DC converter (print) 5 V DC 12 V DC 167 mA 2 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 15.12
3
5% = € 0.75
€ 14.37
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 15.12 / piece)
€ 15.12
plus VAT.
Only 9 Piece(s) available
Highlights & Details
TracoPower TMR 0512 DC/DC converter (print) 5 V DC 12 V DC 167 mA 2 W No. of outputs: 1 x Content 1 pc(s)
- 3 year guarantee
- Low remaining ripple
- Remote on/off
- Protected against permanent short circuit
Technical specifications
- Ripple: (20 MHz BW)< 50 mVpp
- Product type
DC/DC converter (print)
- Type
TMR 0512
- Nominal voltage
5 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
9 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
167 mA
- Output current (max.) - rounded
167 mA
2 W
- Insulation voltage
1000 V DC
- Enclosure
SIL
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 21.8 x 9.2 x 11.1 mm
- Height
11.1 mm
- Length
21.8 mm
- Width
9.2 mm
- Content
1 pc(s)
2 W
- Output voltage
12 V DC
- Output current (details)
167 mA
- Type
TMR Series
- Operating temperature
-40 - +75 °C
- Insulation voltage
I/O 1000 V DC
- Mains control
max. ±0.5 %
Documents & Downloads
Datasheet
Datasheet 154558 TracoPower TMR 0512 DC/DC converter (print) 5 V DC 12 V DC 167 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 154558 TracoPower TMR 0512 DC/DC converter (print) 5 V DC 12 V DC 167 mA 2 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 154558 TracoPower TMR 0512 DC/DC converter (print) 5 V DC 12 V DC 167 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154558 TracoPower TMR 0512 DC/DC converter (print) 5 V DC 12 V DC 167 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Description
2 W in miniature SIL casing, regulated output, wide-range input 2:1. No external capacitor required. Permanent short-circuit protection. Remote on/off: power consumption in shut down state max. 1 mA. Plastic casing (UL94V-0 class). MTBF > 2.3 million hours at +25 ºC.
