TracoPower TOS 10-05SM DC/DC converter (component) 5 V DC 3.3 V DC 10 A No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 30.24
30
4% = € 1.32
€ 28.92
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 30.24 / piece)
€ 302.40
plus VAT.
Highlights & Details
DC/DC converter TOS series, not insulated (PIN) converter
- 3-year manufacturer's guarantee
Technical specifications
- Control deviations: input change ±0.3 %, load change ±0.4 %
- Ripple: (Input 5/12 V/DC) 50/75 mVpk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (component)
- Type
TOS 10-05SM
- Nominal voltage
5 V DC
- Min. input voltage
2.4 V DC
- Input voltage (max.)
5.5 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
10 A
- Output current (max.) - rounded
10 A
- Efficiency (max.)
93 %
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 33 x 13.5 x 8.28 mm
- Height
8.28 mm
- Length
33 mm
- Width
13.5 mm
- Content
1 pc(s)
- Type
TOS Series
- Operating temperature
(Note derating) -40 to +85 °C
Documents & Downloads
Datasheet
Datasheet 3370013 TracoPower TOS 10-05SM DC/DC converter (component) 5 V DC 3.3 V DC 10 A No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370013 TracoPower TOS 10-05SM DC/DC converter (component) 5 V DC 3.3 V DC 10 A No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370013 TracoPower TOS 10-05SM DC/DC converter (component) 5 V DC 3.3 V DC 10 A No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370013 TracoPower TOS 10-05SM DC/DC converter (component) 5 V DC 3.3 V DC 10 A No. of outputs: 1 x Content 1 pc(s)
Description
High power density, adjustable output voltage and a very high degree of efficiency. Fast transient settling time, low voltage cut-off, remote on/off.
