Walther Werke FW110306CC CEE wall socket 16 A 3-pin 230 V 1 pc(s)
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 11.76
3
5% = € 0.59
€ 11.17
5
7% = € 0.82
€ 10.94
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 11.76 / piece)
€ 11.76
plus VAT.
Highlights & Details
CEE NEO wall socket 16A 3P 6h
- CEE NEO wall socket 16A 3P 6h
- Protection class: IP54
- With spring-cage technology
- This text is machine translated.
Technical specifications
- Voltage according to EN 60309-2: 200-250 V (50+60 Hz) blue
- Voltage according to IEC 60309 (series I): 200V-250V
- Voltage according to IEC 60309 (series II): Normative not assigned
- Time setting 6 h
- Colour code blue
- Conductor cross-section (rigid) 1.5 - 4 mm
- Conductor cross-section (flexible) 1 - 2.5 mm
- Protection class (IP)IP54
- Screwless terminal
- Cable entry: Pre-punched
- Material: Plastic
- Contact material CuZn
- Surface treatment contacts untreated
- Flammability class of housing: V2
- Flammability class of the contact carrier: V0
- Mounting type: Inside mounting
- Product type
CEE wall socket
- Nominal voltage
230 V
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Type B
CEE connector (3-pin, 16 A)
- Cores
3
IP54
- Factory colour
Black
- Dim
(L x W x H) 300 x 150 x 100 mm
- Length
300 mm
- Width
150 mm
- Height
100 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3015690 Walther Werke FW110306CC CEE wall socket 16 A 3-pin 230 V 1 pc(s)
Description
Features
- With spring-cage technology
- With "blue" color ring coding
- For 200 V~ voltage
- Housing made of PA6 material
- With highly heat resistant contact carrier made of PA66 material
- And a M20 cable entry at the top
- For interior mounting
Scope of delivery
- CEE NEO wall socket 16A 3P 6h
- User manual.
