Name: Aim TTi MX100T Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 315 W LAN programmable No. of outputs 3 x
Brand: Aim TTi
SKU: 1418440
Availability: BackOrder

A digital laboratory power supply with three outputs, displaying voltages and currents: 16V/6A, 35V/4A, 7V/1.5A. Various controls and indicators visible.

EAN:

Part number:

Item no:

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1,405.00 / piece)

€ 1,405.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

3-channel laboratory power supply aim TTi MX100T, 0 to 16 V, 0 to 35 V, 0 to 70 V

No. of outputs 3 x
0 - 35 / 0 - 6 A
0 - 35 V DC / 0 - 6 A
0 - 70 V DC / 0 - 3 A
315 W
LAN
programmable

Technical specifications

Type: MX100T

Product type: Bench PSU (adjustable voltage)

No. of outputs: 3 x

: 315 W

Technology: Linear regulated PSU

Interfaces: LAN

Features: programmable

Dim: (L x W x H) 270 x 510 x 340 mm

: Manufacturer's standards (no certificate)

Input voltage: 115 V AC
230 V AC

Weight: 5.8 kg

Connections: Connection terminal 4 mm

Output: LXI

Output voltage (max.): 35 V DC

Output voltage (min.): 0 V DC

Output voltage 2 (max.): 35 V DC

Output voltage 2 (min.): 0 V DC

Output voltage 3 (max.): 70 V DC

Output voltage 3 (min.): 0 V DC

Max. output current: 6 A

Output current (min.): 0 A

Output current 2 (max.): 6 A

Output current 2 (min.): 0 A

Output current 3 (max.): 3 A

Output current 3 (min.): 0 A

Width: 510 mm

Height: 340 mm

Length: 270 mm

Residual ripple: 3 mV

Max. temperature: +40 °C

Min. temperature: +5 °C

Variants(All information include VAT, plus shipping costs)

Input voltage

No. of outputs

Output current

Output voltage

Output voltage 3 (range)

Power

Aim TTi MX100T Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 315 W LAN programmable No. of outputs 3 x

Item no:1418440

Available soon

Conrad Electronic

This article

115 V AC

3 x

0 - 6 A

0 - 35

0 - 70 V DC

315 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1,405.00^*

Aim TTi MX100Q-S2 Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 420 W RS232, USB , LAN OVP No. of outputs 4 x

Item no:3131386

Available soon

Conrad Electronic

110 V AC

4 x

0 - 6 A

0 - 35

0 - 70 V DC

420 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2,145.00^*

Aim TTi MX100QP-S2 Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 420 W RS232, USB , LAN, GPIB remote controlled, OVP, programmable No. of outputs 4 x

Item no:3131385

Available soon

Conrad Electronic

110 V AC

4 x

0 - 6 A

0 - 35

0 - 70 V DC

420 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2,375.00^*

Aim TTi MX100TP Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 315 W RS232 programmable No. of outputs 3 x

Item no:1418463

Fast track dispatch on Thu 29 Oct

1 Piece(s)Conrad Electronic

115 V AC

3 x

0 - 6 A

0 - 35

0 - 70 V DC

315 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1,729.00^*

Aim TTi MX103Q-S2 Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 420 W RS232, USB , LAN OVP No. of outputs 4 x

Item no:3131389

Available soon

Conrad Electronic

110 V AC

4 x

0 - 6 A

0 - 35

0 - 35 V DC

420 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2,145.00^*

Aim TTi MX103QP-S2 Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 420 W RS232, USB , LAN, GPIB programmable, remote controlled, OVP No. of outputs 4 x

Item no:3131387

Available soon

Conrad Electronic

110 V AC

4 x

0 - 6 A

0 - 35

0 - 35 V DC

420 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2,375.00^*

Aim TTi MX180T Bench PSU (adjustable voltage) 0 - 120 0 - 3 A 18 W, 180 W USB programmable No. of outputs 3 x

Item no:1418441

Available soon

Conrad Electronic

115 V AC

3 x

0 - 3 A

0 - 120

0 - 12 V

18 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1,555.00^*

Aim TTi MX180TP Bench PSU (adjustable voltage) 0 - 60 0 - 3 A 18 W, 180 W LXI programmable No. of outputs 3 x

Item no:1418464

Available soon

Conrad Electronic

115 V AC

3 x

0 - 3 A

0 - 60

0 - 12 V

18 W

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1,895.00^*

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1418440 Aim TTi MX100T Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 315 W LAN programmable No. of outputs 3 x

Information

Information 1418440 Aim TTi MX100T Bench PSU (adjustable voltage) 0 - 35 0 - 6 A 315 W LAN programmable No. of outputs 3 x

Description

The MX100T is a 315 W power supply with high precision for laboratories with three full-fledged outputs, each of which has several areas. The MX100T-power supply has a large graphic LCD with backlight, on the complete settings for all three outputs can be displayed at the same time, as well as a quick and intuitive user interface with other display modes and menus as needed.

This text is machine translated.

Features

Three high-power outputs of resp. 105 W
3 x (0 to 35 V at 0 to 3 A)
Total power of 315 W in a compact housing
Range Switching provides for up to 70 V and up to 6 A
Twelve range combinations for maximum flexibility
Up to 210 W from a single output
Low output noise and low ripple via linear endre locking; height adjustment resolution up to 1 mV and 0.1 mA
Changing the activation of the surge protection and over-current protection on all outputs
50 Setting memory per output as well as 50 linked memory
Selectable Voltage Tracking
Selectable averaging of the current measuring device
Switchable Remote scanning on all outputs; graphic LCD offers simultaneous output measurement display
Numerical or dial control of all parameters
Individual or combined on and off of output with programmable delay sequencing
3U housing for tabletop or rack mounting

Description

Features

Three high-power outputs of resp. 105 W
3 x (0 to 35 V at 0 to 3 A)
Total power of 315 W in a compact housing
Range Switching provides for up to 70 V and up to 6 A
Twelve range combinations for maximum flexibility
Up to 210 W from a single output
Low output noise and low ripple via linear endre locking; height adjustment resolution up to 1 mV and 0.1 mA
Changing the activation of the surge protection and over-current protection on all outputs
50 Setting memory per output as well as 50 linked memory
Selectable Voltage Tracking
Selectable averaging of the current measuring device
Switchable Remote scanning on all outputs; graphic LCD offers simultaneous output measurement display
Numerical or dial control of all parameters
Individual or combined on and off of output with programmable delay sequencing
3U housing for tabletop or rack mounting
