![Potentiometer with multiple terminals, metal casing and long shaft; electronic component for controlling resistance.<br><br>[Note: This appears to already be quite close to British English, so minimal changes were needed.]](https://asset.conrad.com/media10/isa/160267/c1/-/en/1694246_BB_00_FB/image.jpg?x=400&y=400&format=jpg&ex=400&ey=400&align=center)
1/2
Image similar
Alpha 63250-01400/A100K APM4A100KM Single turn rotary pot Mono 50 mW 100 kΩ 1 pc(s)
Product type
Single turn rotary pot
Resistance
100 kΩ
Resistance characteristic
logarithmic
Output
Mono
Power rating
50 mW
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 7.99 / piece)
€ 7.99
incl. VAT
14-day return policy included
Highlights & Details
Rotary potentiometer
- 100 kΩ
- logarithmic
Technical specifications
- Product type
Single turn rotary pot
- Resistance
100 kΩ
- Resistance characteristic
logarithmic
- Output
Mono
- Power rating
50 mW
- Cut-off voltage
150 V
- Connection
Print
- Mechanical angle
270°
- Torque (max.)
2 Ncm
- Axle length
30 mm
- Axle type
Metal
Smooth
Round
- Axle Ø
4 mm
- Thread size
M7
- Thread length
8 mm
- (Ø)
4 mm
- Min. temperature
-25 °C
- Max. temperature
70 °C
- Tolerance ±
20 %
- Content
1 pc(s)
- Type
APM4A100KM
- Dim
(Ø) 4 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1694246 Alpha 63250-01400/A100K APM4A100KM Single turn rotary pot Mono 50 mW 100 kΩ 1 pc(s)
Description
Scope of delivery
- 63250-01400/A100K.
