Alpha 63250-01400/A10K APM4A10KM Single turn rotary pot Mono 50 mW 10 kΩ 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Single turn rotary pot
Resistance
10 kΩ
Resistance characteristic
logarithmic
Output
Mono
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.03
5
6% = € 0.32
€ 4.71
10
9% = € 0.46
€ 4.57
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.03 / piece)
€ 5.03
plus VAT.
14-day return policy included
Highlights & Details
Rotary potentiometer
- 10 kΩ
- logarithmic
Technical specifications
- Packaging type
Piece
- Product type
Single turn rotary pot
- Resistance
10 kΩ
- Resistance characteristic
logarithmic
- Output
Mono
- Power rating
50 mW
- Cut-off voltage
150 V
- Connection
Print
- Mechanical angle
270°
- Torque (max.)
2 Ncm
- Axle length
30 mm
- Axle type
Metal
Smooth
Round
- Axle Ø
4 mm
- Thread size
M7
- Thread length
8 mm
- (Ø)
4 mm
- Min. temperature
-25 °C
- Max. temperature
70 °C
- Tolerance ±
20 %
- Content
1 pc(s)
- Type
APM4A10KM
- Dim
(Ø) 4 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1694243 Alpha 63250-01400/A10K APM4A10KM Single turn rotary pot Mono 50 mW 10 kΩ 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 1694243 Alpha 63250-01400/A10K APM4A10KM Single turn rotary pot Mono 50 mW 10 kΩ 1 pc(s) Piece
Description
Scope of delivery
- 63250-01400/A10K.
