BACO BA223982 L61QB21 Double head pushbutton Front ring (PVC), chrome-plated Green, Red 1 pc(s)

A green 'I' at the top and a red 'O' at the bottom on an oval switch, with an empty grey field in the centre.
Technical drawing of a plug with dimensions: width 32.25 mm, height 11.05 mm, total circumference 53.9 mm, connection width 29.9 mm.
1/2
Image similar
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
4 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 15.99 / piece)
€ 19.99
-20 %
€ 15.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
Only 4 Piece(s) available
14-day return policy included
Report legal concerns

Highlights & Details

BACO BA223982 L61QB21 Double head pushbutton Front ring (PVC), chrome-plated Green, Red 1 pc(s)

  • 10-year guarantee.
  • 'UL' Mark: A test mark in a circle with the letters 'c' on the left and 'us' on the right. Stands for safety certification.

Technical specifications

  • Approval: EN-IEC 60947-5-1
Product type

Double head pushbutton

Switch/button features

Front ring (PVC)

chrome-plated

Lighting type

None

Factory colour

Green

Red

Print motif

0/I

Connection

External contact

Functions

momentary

Recess diameter

22.3 mm

Type

2 x groping/buttons

IP66

Length

53.9 mm

Width

29.9 mm

Height

17 mm

Content

1 pc(s)

Dim

(L x W x H) 53.9 x 29.9 x 17 mm

Type

L61QB21

Type

L61QB21

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 701560 BACO BA223982 L61QB21 Double head pushbutton Front ring (PVC), chrome-plated Green, Red 1 pc(s)

Conformity certificate

Conformity certificate 701560 BACO BA223982 L61QB21 Double head pushbutton Front ring (PVC), chrome-plated Green, Red 1 pc(s)

Warranty Terms

Warranty Terms 701560 BACO BA223982 L61QB21 Double head pushbutton Front ring (PVC), chrome-plated Green, Red 1 pc(s)

Description

BACO, a modular system of command and warning devices, with protection against mechanical load IK05 and various permissions. A complete unit consists of the following components:
Push-button actuator flat /super flat/rotary switch/double push button
Adapter 1.3 or 5-compartment,
Contact element, opener and closer.

Scope of delivery

  • front element with attached nut.
