Name: BKL Electronic SIL socket (standard) No. of rows: 1 Pins per row: 14 10122209 1 pc(s) Tray
Brand: BKL Electronic
SKU: 2356409
Availability: InStock

A black, rectangular electronic chip with protruding metal pins designed for connection in an electrical circuit.

Technical drawing of a 16-pin connector with precise dimensional specifications. Shows pin positioning and spacing.

1/2

Packaging type

Tray

Connector type

Power strip, straight

Product type

SIL socket (standard)

No. of rows

Total number of pins

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

212 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 3

Total (€ 1.49 / piece)

€ 4.47

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Female header single row 14 way, straight, gold plated, grid 2.54mm, overall height 8.5mm, cannot be separated

Content 1 pc(s)
No. of rows 1
Pins per row 14

Our service for you

Technical specifications

Packaging type: Tray

Connector type: Power strip, straight

Product type: SIL socket (standard)

No. of rows: 1

Pins per row: 14

Total number of pins: 14

CS: 2.54 mm

Connection: Print

Factory colour: Black

Pin shape: Rectangular

Nominal voltage: 600 V

Nominal current: 3 A

Nominal current - rounded value: 3 A

Contact surface: Gold plated

Contact material: Brass

Case material: PBT

Pin length (PCB): 3.20 mm

Separable: No

Connector orientation: Perpendicular (to the PCB)

Manufacturer part #: 10122209

Socket depth: 2.50 mm

Content: 1 pc(s)

Height: 8.50 mm

RoHS-compliant: Yes

Max. temperature: +105 °C

Min. temperature: -40 °C

Type: 10122209

Variants(All information include VAT, plus shipping costs)
