Highlights & Details

Power analyzer for single-phase and symmetrical three-phase networks

Measurement of very weak and very strong currents
Analysis of energy quality
Analysis of phase shift
Energy balance
Data-logger function
Representation of the signal form of the starting current of a motor

Technical specifications

Voltage range: From 6 Vrms to 600 Vrms AC+DC ±(0.5 % +2 D)
AC current range: From 100 mA to 6500 A ±(0.5% +1 D)
DC current range: From 100 mA to 1700 A ±(1% +1 D)
Min, max, average and peak values (+ and -),
Crest factor CF
Base frequency: From 40 Hz to 70 Hz
Screen: Backlit 173 segment LCD
Power W, VA, var, PF, cos φ
Power varh and VAh, Wh
Harmonics: Up to 50. Order
Engine speed: From 6 RPM to 120 RPM ±(0.5%)
Temperature (PT100 probe): From -200 °C to +850 °C ±(1% +10 D)
Winding resistance: From 0.0 Ω to 2000 Ω ±(0.5 % +2 Ω)
Protection class: IP54

Product type: Network diagnostics

Reading category: CAT IV 600 V

Display (details): Digital display b/w

: Manufacturer's standards (no certificate)

Dim: (L x W x H) 6 x 21.1 x 10.8 cm

Weight: 840 g

Measurement type: 1-phase

Features: Data logger

Width: 21.1 cm

Height: 10.8 cm

Length: 6 cm

Interfaces: RS232
USB

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1666200 Chauvin Arnoux C.A 8220 Network diagnostics 1-phase Data logger

User & Safety Instructions

User & Safety Instructions 1666200 Chauvin Arnoux C.A 8220 Network diagnostics 1-phase Data logger

Description

The C.A 8220 is fully geared toward electrical engineering and the monitoring of electrical machines: An ideal tool for monitoring and maintenance teams in industry. With its liquid crystal segment display, compact and shock-resistant housing and ergonomic user interface, the device is easy and intuitive to use. The C.A 8220 provides an immediate picture of the most important data of a single-phase or a symmetric three-phase network.
The device measures all the parameters important for the inspection of electrical machines. Thanks to its accuracy and wide range of current transformers, the current measuring range ranges from several milliamps to several thousand amps.

Further functions include:
Speed measurement: In the context of preventive maintenance, regular checking of the speed of electrical drives is essential. As a universal measuring device, the C.A 8220 also does this task simply and efficiently.
Temperature measurement: Today, most electric drives are equipped with integrated temperature sensors whose output signal is available at the terminal box. By simply tapping this signal, the C.A 8220 directly displays the motor temperature.
Each C.A 8220 is delivered with the software PAT (Power Analyzer Transfer), with which the measurement results can be displayed and evaluated on the PC. This software is available as a download free of charge.
