Name: Chauvin Arnoux P01654110 C.A 1110 Lux meter 0.1 - 200000 lx
Brand: Chauvin Arnoux
SKU: 1593629
Availability: InStock

There is a Conrad shop in your region. You can shop in your own language, have access to your local customer service and enjoy local transport for your purchase.

Go to local shop

Conrad
To search for the product, enter a catchphrase, an article number, an EAN or a part number
My account

Log in / Register
Shopping cart

Subscribe to the newsletter and receive a €5 voucher Subscribe to the newsletter and receive a €5 voucher
Procurement

Order & eProcurement

All order and procurement services
Services

All Services
Offers %

A digital light metre, Model C.A 1110, displays a measurement of 517.8 lux on the screen. The light sensor is positioned at the top.

Digital luxmeter with blue backlit display showing a measured value of 517.8 lx. Used for measuring light intensity.

Light meter with digital display shows '517.8'. Included are a matching case, three batteries and a USB cable.

Digital light meter with large display shows measurement value of '517.8 lx'. A sensor is connected by a cable.

A person is holding a digital light meter with a display showing a light intensity of 5,178 lux. The device has an external sensor lens.

A person is holding a light meter displaying 198.4 in front of a laptop with a diagram on the screen in an office.

1/7

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

4 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 539.00 / piece)

€ 539.00

incl. VAT

Only 4 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

C.A 1110 Luxmeter+Data Logger

Compensation of spectral error in LED or fluorescent light sources
Map curve representation of the illuminance on a surface or in a room
IEC spectral correction and angle correction
Large illuminated display
Separate light sensor for avoiding shadow formation by the operator or fixable at the device for one-handed measurements
Storage of up to 1 million measured values
Can be networked via USB or Bluetooth
Software Data Logger Transfer with automatic reporting

Technical specifications

Resolutions:
0.1 lx (from 0.1 lx to 999.9 lx)
1 lx (from 1 000 lx to 9 999 lx)
10 lx (from 10 000 lx up to 99.99 klx)
100 lx (from 100 klx)

Product type: Lux meter

Reading type: Light intensity

: Manufacturer's standards (no certificate)

Dim: (L x W x H) 32 x 150 x 72 mm

Display: Numeric

Weight: 345 g

Features: Suitable for LED lighting
Data logger

Illuminance reading range: 0.1 - 200000 lx

Illuminance reading range (max.): 200000 lx

Illuminance reading range (min.): 0.1 lx

Width: 150 mm

Height: 72 mm

Length: 32 mm

Interfaces: Bluetooth®
USB

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 1593629 Chauvin Arnoux P01654110 C.A 1110 Lux meter 0.1 - 200000 lx

User & Safety Instructions

User & Safety Instructions 1593629 Chauvin Arnoux P01654110 C.A 1110 Lux meter 0.1 - 200000 lx

Description

The Luxmeter C.A 1110 is intended to be used for measuring the intensity of illumination of all light sources (filament lamps, LED, fluorescent lights, etc.) up to 200 000 Lux according to class C according to Franz. Standard NF C 42-710.

Thanks to the MAP-curve display, it is possible to check the uniform illumination of a surface or of a room.

The separate light sensor can be attached with its magnetic holder on the device for measurements with one hand and to facilitate the transportation, or remove from the device, in order to avoid the formation of shadows by the operator.

The C.A 1110 is available via the functions Min, Max, Average Value and hold and the measured values can be stored manually or via programming.

With the free downloadable Software Data Logger Transfer, you can monitor the current and the stored measurement data is displayed on the PC, the device is configured and reports can be created.

This text is machine translated.

Features

Measurement range: From 0.1 lx to 200 000 lx (Lux)
Self-deviation (without compensation):
± 3% of the display for incandescent lamps (standard)
± 6% of the display for LEDs (from 3000 K to 6000 K)
± 9% of the display for fluorescent lamps
Functions: Min, Max, Average, MAP, Hold, lx or fc / Display illumination
Storage of up to 1 million measured values
USB or Bluetooth interfaces
Housing protection class IP50
Dimensions of housing: 150 x 72 x 32 mm / Light sensor: 67 x 64 x 35 mm
Weight 345 g (with batteries)
Suitable for Multifix accessories
Shock protection sleeve available as an accessory

Scope of delivery

Bag
3 alkaline batteries 1.5 V AA
USB cable
Test report and short instructions (complete instructions and Software Data Logger Transfer, on the Chauvin Arnoux Website - available)

Description

Features

Measurement range: From 0.1 lx to 200 000 lx (Lux)
Self-deviation (without compensation):
± 3% of the display for incandescent lamps (standard)
± 6% of the display for LEDs (from 3000 K to 6000 K)
± 9% of the display for fluorescent lamps
Functions: Min, Max, Average, MAP, Hold, lx or fc / Display illumination
Storage of up to 1 million measured values
USB or Bluetooth interfaces
Housing protection class IP50
Dimensions of housing: 150 x 72 x 32 mm / Light sensor: 67 x 64 x 35 mm
Weight 345 g (with batteries)
Suitable for Multifix accessories
Shock protection sleeve available as an accessory

Scope of delivery

Bag
3 alkaline batteries 1.5 V AA
USB cable
Test report and short instructions (complete instructions and Software Data Logger Transfer, on the Chauvin Arnoux Website - available)
