Cimco 18 2362 Ferrule 25 mm² Partially insulated Yellow 50 pc(s)
Product type
Ferrule
Cross section per core
25 mm²
Sleeve length
16 mm
Insulation type
Partially insulated
Content
50 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 7.99 / piece)
€ 7.99
incl. VAT
14-day return policy included
Highlights & Details
Insulated wire-end sleeves according to DIN 46228 and special dimensions
- 30 mm
- Yellow
Technical specifications
- Product type
Ferrule
- Cross section per core
25 mm²
- Sleeve length
16 mm
- Insulation type
Partially insulated
- Factory colour
Yellow
- Country colour code
DIN
- Content
50 pc(s)
- Contact material
CU-ETP
- AWG max.
4
- Manufacturer part #
18 2362
- Insulation material
PP
- Length
30 mm
- Cross-section x Length
25 mm² x 16 mm
- RoHS-compliant
Yes
- Temperature range
-35 - +105 °C
- Type
182362
- Insulation
Polypropylene
- Material (details)
Cu-ETP according to DIN EN 13600
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 735777 Cimco 18 2362 Ferrule 25 mm² Partially insulated Yellow 50 pc(s)
User & Safety Instructions
User & Safety Instructions 735777 Cimco 18 2362 Ferrule 25 mm² Partially insulated Yellow 50 pc(s)
Description
Scope of delivery
- 50.
- This text is machine translated.
