Contacts, seals, blind plugs and tools for 2- and 3-pin SUPERSEAL Pins: 1 183036-1 183036-1 TE Connectivity Content: 1 p
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.29
50
7% = € 0.02
€ 0.27
100
14% = € 0.04
€ 0.25
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.29 / piece)
€
Technical specifications
- Content
1 pc(s)
- Height
5.2 mm
- Length
4.7 mm
- Width
22.7 mm
- Industrial packaging
No
- Total number of pins
1
IP67
- Connection
Crimp
- Contact surface
Tin plated
- Pin shape
Rectangular
- Connector system
automotive
- Series
AMP-Superseal 1.5mm Series
- Manufacturer part #
183036-1
- Type
183036-1
- Type
Pin contact
- Nominal current
6 A
- Nominal voltage
24 V DC
- max. cross section
0.50 mm²
- Connector type
Pin
- Cross section
0.3 - 0.5 mm²
- Pins
1
- Connection
-
- Contact material
Copper alloy
- Min. cross section
0.35 mm²
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- Product type
Documents & Downloads
Datasheet
Datasheet 749718 Contacts, seals, blind plugs and tools for 2- and 3-pin SUPERSEAL Pins: 1 183036-1 183036-1 TE Connectivity Content: 1 p
User & Safety Instructions
User & Safety Instructions 749718 Contacts, seals, blind plugs and tools for 2- and 3-pin SUPERSEAL Pins: 1 183036-1 183036-1 TE Connectivity Content: 1 p
Description
AMP-SUPERSEAL 1.5 plug connectors are particularly well suited to applications in areas where the connector not only needs to be watertight but also resistant to aggressive ambient factors such as ozone, salts, petrol, diesel, brake fluid and engine oils. The associated stringent requirements for technical reliability and watertightness are met by this series, which satisfies the specifications laid down in IEC 529 and DIN 40 50 IP67, while this plug connector remains easy to handle. This explains the widespread use of these connectors in various sectors of industry for applications related to power supplies or the use of sensors. Bush case, pin case and protective cover for 2- and 3-pin SUPERSEAL
Scope of delivery
- individual items
- This text is machine translated.
