Davis Instruments 6415 Anemometer External sensor
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 865.00 / piece)
€ 865.00
incl. VAT
Only 1 Piece(s) available
Highlights & Details
Ultrasound anemometer Vantage PRO
- Wear-free and low maintenance: No moving parts mean no mechanical wear, no lubrication and minimal maintenance. Ideal for long-term, trouble-free operation
- Highest precision: Ultrasound technology provides exceptionally accurate wind speed and direction measurements, even at the lowest wind speeds or sudden gusts.
- Antifreeze to freezing: Without rotating parts, the anemometer is resistant to freezing and WAS ensures reliable operation even in winter conditions.
- Robust design: Designed to withstand the harshest weather conditions, from strong winds to extreme temperatures, and offers outstanding durability.
- Seamless integration: Specially designed for the Davis Vantage Pro and Vantage Pro2 weather stations, the ultrasonic anemometer can be easily integrated and extends the capabilities of your existing system.
- Faster update rates: Get wind data at very short intervals to accurately capture even the finest changes in wind conditions.
Technical specifications
- Sensor type: Ultrasonic sensor.
- Length of connected cable: 40' (12 m).
- Cable type 4-wire, 26 AWG.
- Connection: Modular plug (RJ-11).
- Maximum cable length 250' (76 m).
- Note: The maximum displayable wind speed decreases as the cable length increases.
- Material control head: Polyacetal.
- Material Anemometer-arm: Clear anodized aluminum
- Built-in power supply: Its own solar panel charges an internal battery.
- Wind speed resolution
1 km/h
- Product type
Anemometer
- Temperature reading range
-15 up to +55 °C
- Wind speed
144 km/h
- Automatic temperature compensation
Yes
- Dim
(L x W) 380 mm x 60 mm
- Features
External sensor
- Weight
200 g
- Temperature reading range (max.)
+55 °C
- Temperature reading range (min.)
-15 °C
- Width
60 mm
- Length
380 mm
- Power supply (details)
The battery is charged by the solar cell only.
Documents & Downloads
Datasheet
Datasheet 3448771 Davis Instruments 6415 Anemometer External sensor
User & Safety Instructions
User & Safety Instructions 3448771 Davis Instruments 6415 Anemometer External sensor
Description
Revolutionary wind measurement: Ultrasound anemometer for Davis Instruments Vantage Pro
Experience the next generation of the wind measurement with the ultrasound anemometer for your Davis Vantage pro weather station! This state-of-the-art sensor package uses advanced ultrasonic technology to capture wind speed and direction without moving parts. This means: No wear, no maintenance and unsurpassed precision – even in extreme conditions. Forget traditional shell anemometers that are susceptible to icing or wear. The ultrasound anemometer provides continuously reliable and accurate wind data for your most important decisions.
Upgrade your weather station to the future and measure the wind with unbeatable reliability!
